Home > Lights & Lighting > Stage Lighting > Effect Light > 2016 Professional Gobo Stage Light 330 Beam Light

2016 Professional Gobo Stage Light 330 Beam Light

2016 Professional Gobo Stage Light 330 Beam Light thumbnail-1
2016 Professional Gobo Stage Light 330 Beam Light thumbnail-2
2016 Professional Gobo Stage Light 330 Beam Light thumbnail-3
2016 Professional Gobo Stage Light 330 Beam Light thumbnail-4
2016 Professional Gobo Stage Light 330 Beam Light thumbnail-5
2016 Professional Gobo Stage Light 330 Beam Light thumbnail-6
2016 Professional Gobo Stage Light 330 Beam Light photo-1
2016 Professional Gobo Stage Light 330 Beam Light photo-2
2016 Professional Gobo Stage Light 330 Beam Light photo-3
2016 Professional Gobo Stage Light 330 Beam Light photo-4
2016 Professional Gobo Stage Light 330 Beam Light photo-5
2016 Professional Gobo Stage Light 330 Beam Light photo-6
US$ 700 - 800 MOQ: 1 Piece
Key Specifications
Get Latest Price
Light Source:
Induction Lamps
Input Voltage(V):
100-240V
Lamp Power(W):
330
Contact Supplier Request Quote Chat Now
Guangzhou Jin Zhi Hui Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Light Source Induction Lamps
Input Voltage(V) 100-240V
Lamp Power(W) 330
Lamp Luminous Flux(lm) 12560
Lamp Luminous Efficiency(lm/w) 90
Color Temperature(CCT) Warm White
Working Temperature(℃) -20, 45
Working Lifetime(Hour) 2000
IP Rating IP54
Certification CE, EMC
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name Toppest
Model Number professional 15R stage edge lights

2016 professional gobo stage light 330 beam light



Product Description



Technical parameters



 power supply: AC 100-240 V,50/60Hz

power consumption:500w

lamp life:2000

DMX CHS: 16/14/22 CHS

color wheel: 8 color +open

gobo wheel I: 8 interchangeable ,rotating gobos+open

gobo wheel II: 13 static gobos + open

prism:3/8 facet-rotating prism with 16 prism macros Dimmer intensity from 0%-100%

focus :Motorized focus

display :can be changed 180 degree reverse to fit for different installation positition

stobe/shutter:hight speed shutter,0-13 hz or random strobe

packing:65*46*42.5CM

N.W.:23kg

G.W.:27kg





DMX Channels



Item

Channels

DMX address

Content

1

Strobe

0-50

Light on

51-240

Strobe from slow to fast

241-255

Light on

2

Light on

0-150

Off to on

151-255

Light on

3

X axis

0-255

0-540 degrees

4

Y axis

0-255

0-270 degrees

5

X.Y speed

0-255

Fast to slow

6

















color

0-12

White color

13-25

Color 1

26-37

Color 2

38-50

Color 3

51-63

Color 4

64-76

Color 5

77-90

Color 6

91-103

Color 7

104-116

Color 8

117-128

Color 9

129-192

Anti-clockwise,slow fo fast

193-255

Clowckwise,slow to fast

7

Semi color

0-255

Semi color function

8















Gobo

0-6

white color

7-13

Gobo 1

14-20

Gobo 2

21-27

Gobo 3

28-34

Gobo 4

35-41

Gobo 5

42-48

Gobo 6

49-55

Gobo 7

56-62

Gobo 8

63-69

Gobo 9

70-76

Gobo 10

77-83

Gobo 11

84-90

Gobo 12

91-97

Gobo 13

98-104

Gobo 14

105-111

Gobo 15

112-118

Gobo 16

119-127

Gobo 17

128-191

Rainbow effect,clowise rotataion ,slow to fast

192-255

Rainbow effect,anti-clockwise rotation, slow to fast

9

Gobo shake

0-255

0--400°

10

Prism

0-255

Prism

11

Prism rotation

0-126

Prism  adjustment

127-191

Clockwise,fast to slow

192-255

Anti-clockwise,slow to fast

12

Focus

0-255

Near to fat

13

Prism shelf adjustment

0-255

Prism cleartity adjustment

14

Foggy

0-255

Wash effect

15

X fine

0-255

0--5°

16

Y fine

0-255

0--5°





17





Bulb on/off

0-99

No function

100-105

Light off

106-199

No function

200-205

Light on

206-255

No function.It costs over 10 minutes to light bulb again after light off.

18

reset

0-254

No function

255

Reset after 3 to 5 seconds



Product detail show



2016 professional gobo stage light 330 beam light2016 professional gobo stage light 330 beam light2016 professional gobo stage light 330 beam light2016 professional gobo stage light 330 beam light2016 professional gobo stage light 330 beam light



Packaging & Shipping
      Packaging

         Flight case (1pc/flight case)                           Carton (1pc/carton)

2016 professional gobo stage light 330 beam light



Shipping



1,2-3 days for sample



2,7-30 days for mass products



2016 professional gobo stage light 330 beam light



Our Services

Payment term



2016 professional gobo stage light 330 beam light



Why choose us
  1.  We have over 6 years’ experience of stage light.
  2.  We are factory, we can offer better price than Trade Company.
  3.  100% manufacture, 1 year spare parts’ guarantee time (except lamp & CMY)
  4.  Integrated research and development, design, production, sales and service.
  5.  We specialize in High configuration and high quality products.Every material using             inside will be picked up carefully and be fully tested.
  6.  We have professional R&D team who has professional development ability

 Usage range



2016 professional gobo stage light 330 beam light
