Manufacture of copper wire drawing machine
Suzhou Hengxie Machinery Co., Ltd was established in 2005, a total professional in drawing machine field, specialized in copper and aluminium wire drawing machines. Located in Suzhou City, very close to Shanghai, we share a convenient transportation and the most successful working environment.
Our 6,700 square meters of land allows producing a wide range of equipments, developing and researching new products. We always strive to introduce the latest international techniques to update our products.
With management concept of “Excellent quality, Reasonable prices, Superior services”, our hope is to not only meet our customers` expectations but to exceed them.
Here are the machines we have: Copper&Aluminium Rod Breakdown machine, Large and intermediate wire drawing machine with online annealer, Intermediate wire drawing machine, Intermediate wire drawing machine with online annealer, Fine wire drawing machine, Fine wire drawing machine with online annealer, Customized fine wire drawing machine with annealer, Super fine wire drawing machine. As long as we talk, we can always meet your detail requirements.
Our market includes both domestic and overseas. Such as Bangladesh, Egypt, Iran, Malaysia, Syria, Algeria, Kenya, Turkey, South Africa, Latin America and so on.
With the concept of “Stable quality and mutual development”, Hengxie welcome all customers from the world to create a sincere cooperation and win-win benefit in the future.
HXE-13DL (7DL/8DL/9DL/10Dl/11DL)Copper rod breakdown machine with annealing
Inlet:8.0mm(Max) Outlet:1.2mm-3.5mm Max. mechanical speed:1200m/min
HXE-9D Copper rod breakdown machine
Inlet:8.0mm(Max) Outlet:2.2mm-3.2mm Max. mechanical speed:500m/min
HXE-9DT Large-intermediate copper wire drawing machine with online annealer
Inlet:3.0mm-3.5mm Outlet:1.1mm-2.78mm Max Mechanical speed:800m/min
HXE-13DT Large-intermediate copper wire drawing machine with online annealer
Inlet:3.0mm-3.5mm Outlet:0.8mm-2.78mm Max. mechanical speed:800m/min
HXE-17DS Intermediate copper wire drawing machine
Inlet:2.6mm-3.2mm Outlet:0.4mm-1.8mm Max. mechanical speed:2000m/min
HXE-17DST Intermediate copper wire drawing machine with online annealer
Inlet:2.5mm-3.2mm Outlet:0.4mm-1.8mm Max. mechanical speed:1800m/min
HXE-17MDS Intermediate copper wire drawing machine
Inlet:2.5mm-3.2mm Outlet:0.4mm-1.2mm Max. mechanical speed:1500m/min
HXE-17MDST Intermediate copper wire drawing machine with online annealer
Inlet:2.5mm-3.2mm Outlet:0.4mm-1.2mm Max. mechanical speed:1500m/min
HXE-14DT Fine copper wire drawing machine with online annealer
Inlet:0.8mm-1.6mm Outlet:0.25mm-0.6mm Max. mechanical speed:1500m/min
HXE-22DT Fine copper wire drawing machine with online annealer
Inlet:0.6mm-1.2mm Outlet:0.1mm-0.32mm Max. mechanical speed:2000m/min
HXE-24DT Fine copper wire drawing machine with online annealer
Inlet:0.5mm-1.0mm Outlet:0.07mm-0.25mm Max. mechanical speed:2000m/min
HXE-14DS Fine copper wire drawing machine-vertical type
Inlet:0.8mm-1.6mm Outlet:0.25mm-0.6mm Max. mechanical speed:1500m/min
HXE-22DS Fine copper wire drawing machine-vertical type
Inlet:0.6mm-1.2mm Outlet:0.1mm-0.32mm Max. mechanical speed:2500m/min
HXE-24DS Fine copper wire drawing machine-vertical type
Inlet:0.5mm-1.2mm Outlet:0.08mm-0.25mm Max. mechanical speed:2500m/min
HXE-22DW Fine copper wire drawing machine-horizontal type
Inlet:0.6mm-1.2mm Outlet:0.1mm-0.7mm Max. mechanical speed:2500m/min
HXE-24DW Fine copper wire drawing machine-horizontal type
Inlet:0.6mm-1.2mm Outlet:0.08mm-0.5mm Max. mechanical speed:2500m/min
HXE-TH350 Copper wire annealing machine (250 type-350 type-450 type- 500type)
Applicable wire diameter 0.8mm-2.8mm Speed 1000m/min (customized)
HXE-WF 800 / 750 / 650 Coiler machine
Wire diameter:2.0mm-4.0mm/1.5mm-3.5mm/1.5mm-3.5mm Line speed:800m/min (customized)
Machine dimension:2350L*1700W*4800H Take-up bobbin size:800mm/750mm/650mm
HXE-SX 400-500-630 Automatic dual take-up spools (Pneumatic)
Applicable wire diameter : 0.8mm-2.8mm Max. line speed : 1800m/min (Adjustable)
Loop size : 500mm/630mm O.D. Max. loading capacity of loop : 400 KG/Max.
HXE-SX 400-500-630 Automatic dual take-up spools(Manual)
Applicable wire diameter : 0.8mm-2.8mm Max. line speed : 1800m/min (Adjustable)
Loop size : 500mm/630mm O.D. Max. loading capacity of loop : 400 KG/Max.
HXE-40H / 32H / 24H / 40HA Copper wire annealing machine (tinning)
Wire diameter 0.10mm-0.32mm / 0.10mm-0.32mm / 0.10mm-0.32mm / 0.25mm-0.8mm
Numbers of wire 40 / 32 / 24 / 40
Speed 300m/min - 300m/min - 300m/min - 180m/min
HXE-40HG / 32HG / 24HG / 40HL / 32HL / 24HL Copper clad steel wire annealing machine
Wire diameter 0.10mm-0.4mm
Number of wire 40 / 32 / 24 / 40 / 32 / 24
Speed 180m/min - 180m/min - 180m/min - 250m/min - 250m/min - 250m/min -
HXE-400/13DL Aluminum rod breakdown machine
Inlet:9.5mm(Max) Outlet:1.7mm-4.2mm Max. mechanical speed:1200m/min
HXE-400/10DL Aluminum rod breakdown machine
Inlet:9.5mm(Max) Outlet:2.5mm-4.2mm Max. mechanical speed:1000m/min
HXE-13DLA Aluminum rod breakdown machine
Inlet:9.5mm(Max) Outlet:1.7mm-4.0mm Max. mechanical speed:800m/min
HXE-17MDS Intermediate aluminum wire drawing machine
Inlet:4mm(Max) Outlet:0.4mm-2.2mm Max. mechanical speed:1500m/min
HXE-14DS Fine aluminum wire drawing machine-vertical type
Inlet:1.2mm-2.5mm Outlet:0.5mm-0.75mm Max. mechanical speed:1500m/min
HXE-22DS Fine aluminum wire drawing machine-vertical type
Inlet:1.2mm-2.5mm Outlet:0.2mm-0.5mm Max. mechanical speed:2500m/min
HXE-24DS Fine aluminum wire drawing machine-vertical type
Inlet:1.1mm-2.4mm Outlet:0.08mm-0.4mm Max. mechanical speed:2500m/min
HXE-22DW Fine aluminum wire drawing machine-horizontal type
Inlet:1.2mm-2.5mm Outlet:0.2mm-0.5mm Max. mechanical speed:2500m/min
HXE-24DW Fine aluminum wire drawing machine-horizontal type
Inlet:1.1mm-2.4mm Outlet:0.08mm-0.4mm Max. mechanical speed:2500m/min
