Intermediate wire drawing machine with online annealer of copper
- 45 Set / Sets per Month
- Shanghai
- T/T
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | HXE | Model Number: | 17DST |
| Usage: | Drawing |
Product Description
Specification
1. inlet diameter: 2.6mm-3.5mm
2. outlet diameter: 0.4mm-1.6mm
Main technical parameter
Machine type | hXE-17DT | HXE-17DST | HXE-17MDST |
Control system | Traditional analog type /digital control with production record | ||
Inlet diameter | 2.6-3.0mm | 2.6-3.5mm | 2.6-3.2mm |
Outlet diameter | 0.4-1.2mm | 0.4-1.6mm | 0.4-1.2mm |
Max line speed | 1200 | 2000 | 1500 |
Die numbers | 17 | 17 | 17 |
Slip ratio of machine | 18%+12.5% | 20%+15% | 15%+10% |
Frame | Cast iron | Welded by steel plate | |
Capstan | Tungsten | ||
Max capstan diameter | 260mm | 250mm | 252mm |
Spooler bobbin size | 260mm | 250mm | 252mm |
Bobbin loading &unloading type | Double end thimble | ||
Max loading capacity | 500KG/Max | ||
Transmission type | Chain | Precision ground gears | |
Traversing unit | 90W strap speed down motor type | ||
Brake | Magnetic brake/disc brake | ||
Revise system | PID synchronous control spooler | ||
Detecting device | Weight balance by swing arm | ||
Tension control | Air pressure adjust | ||
Main motor | 37KW | 55KW | 37KW |
Spooler motor | 11KW | 11KW | 11KW |
Annealing method | DC three section annealing | ||
Max annealing current | DC1200A | DC2000A | DC15ooA |
Max annealing voltage | DC50V | DC50V | DC50V |
Annealing power | 60KVA | 100KVA | 75KVrA |
Steam quantity | 12kg/h | 12kg/h | 12kg/h |
Cooling water capacity | 300L/min | 400L/min | 300L/min |
Capacity of compressed air | 0.4-0.6Mpa,30L.min | 0.4-0.6Mp,50L/min | 0.4-0.6Mpa,30L/min |
Power source | 380V 50/60HZ | ||
Machine dimension | 13300x3500x3400 | ||
Machine weight | 6500KG | 7500KG | 6500KG |
Ceritification
Packaging&Delivery
Exhibition
Brand of accessories
Inverter : Invoance
Motor :Wannan
Precision resistance: WDD military enterprise
Bearing :NSK
Low voltage equipment: France Schneider
Warranty
6 month for electrical part
12 month for mechanical part
After-sell service
Pre-sale training:In order to guarantee the customers are able fully to operate the rod breakdown machine , if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Remove simple problem
Market share
