copper wire drawing machie for single small diameter/ fine wire drawing machine/cable machine
Specification
Inlet size:0.6mm-1.2mm
Outlet size:0.1mm-0.4mm
Speed:2000m/min
Advantages:
1.High quality
2.High productivity
3.Easy operation
Main technical parameter
Input diameter |
1.2mm -2.5mm |
output diameter |
0.1mm-0.4mm |
Speed |
2000m/min, say 0.25mm, 15kg/hour; 0.35mm, 28kg/hour |
Dies number |
24 |
Outer diameter of the dies |
25mm*8mm thickness |
Slip ratio of m/c |
From No.1 to No.23 ---- 13%, No.24 ----8% |
Main motor |
15KW 3 phase motor+ 15KW inverter |
Spool motor |
3.7KW +3.7 KW inverter |
Loading of capacity |
40-60kg |
Bobbin size |
300mm |
Machine dimension |
2300*1250*1800mm(L*W*H) |
Certification
Package&Delivery
In Exhibition
Market Share
Brand of accessories
Inverter : Invoance
Motor :Wannan
Precision resistance: WDD military enterprise
Bearing :NSK
Low voltage equipment: France Schneider
Warranty
6 month for electrical part
12 month for mechanical part
After-sell service
Pre-sale training:In order to guarantee the customers are able fully to operate the rod breakdown machine , if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Remove simple problem
