Specifications
Hot dipped Galvanized Welded wire meshSurface treatment:electro or hotdipped galvanized
Wire Diameter:BWG26-12
Price is fair
Hot dipped galvanized wire mesh roll wire fencing
Materail:high quality low carbon steel wire,stainless steel wire.
Welding characteristics:galvanized before or after welding.
Surface treatment:hot dipped galvanized,electro galvanized.
Using:industry,agriculture,builing,transportation,mine,filed,lawn,cultivation,fence
guard,decorate,machine,protection and etc.
.
Specification as follw:
Specification List of Welded Wire Mesh: | ||
Opening |
Wire Diameter<BWG> |
|
In inch |
In metric unit(mm) |
|
1/4" x 1/4" |
6.4mm x 6.4mm |
22,23,24 |
3/8" x 3/8" |
10.6mm x 10.6mm |
19,20,21,22 |
1/2" x 1/2" |
12.7mm x 12.7mm |
16,17,18,19,20,21,22,23 |
5/8" x 5/8" |
16mm x 16mm |
18,19,20,21, |
3/4" x 3/4" |
19.1mm x 19.1mm |
16,17,18,19,20,21 |
1" x 1/2" |
25.4mm x 12.7mm |
16,17,18,19,20,21 |
1-1/2" x 1-1/2" |
38mm x 38mm |
14,15,16,17,18,19 |
1" x 2" |
25.4mm x 50.8mm |
14,15,16 |
2" x 2" |
50.8mm x 50.8mm |
12,13,14,15,16 |
Galvanized Fencing Mesh: | ||||
Opening |
Wire Diameter<BWG> |
|||
In inch |
In metric unit(mm) |
|||
2" x 3" |
50mm x 75mm |
2.0mm,2.5mm,1.65mm |
||
3" x 3" |
75mm x 756mm |
2.67mm,2.41mm,2.11mm,1.83mm,1.65mm |
||
2" x 4" |
50mm x 100mm |
2.11mm,2.5mm |
||
4" x 4" |
100mm x 100mm |
2.0mm,2.5mm |
||
Technical Note: | ||||
Mesh |
Wire Diameter |
||
In Inch |
In MM |
Wire Gauge |
In MM |
1/4" x 1/4" |
6.4mm x 6.4mm |
22#-24# |
0.7mm-0.6mm |
3/8" x 3/8" |
10.6mm x 10.6mm |
19#-22# |
1.0mm-0.7mm |
1/2" x 1/2" |
12.7mm x 12.7mm |
16#-23# |
1.6mm-0.6mm |
5/8" x 5/8" |
16mm x 16mm |
18#-21# |
1.2mm-0.8mm |
3/4" x 3/4" |
19.1mm x 19.1mm |
16#-21# |
1.6mm-0.8mm |
1" x 1/2" |
25.4mm x 12.7mm |
16#-20# |
1.6mm-0.9mm |
1" x 1" |
25.4mm x 25.4mm |
14#-21# |
2.0mm-0.8mm |
11/2" x 11/2" |
38mm x 38mm |
14#-19# |
2.0mm-1.0mm |
1" x 2" |
25.4mm x 50.8mm |
14#-16# |
2.0mm-1.6mm |
2" x 2" |
50.8mm x 50.8mm |
12#-16# |
2.6mm-1.6mm |
Key words:welded wire mesh,electro galvanized welded wire mesh,hot dipped galvanized Welded wire mesh ,1/4inch galvanized welded wire mesh ,pvc coated welded wire mesh fence,heavy gauge welded wire mesh, 6x6 concrete reinforcing welded wire mesh, welded rabbit cage wire mesh,stainless steel welded wire mesh,concrete renforcement welded wire mesh,1x1welded wire mesh,square mesh,building materials.
Production photoes
PACKING AND LOADING
ABOUT OUR FACTORY
