Specifications
CBT-65 Razor wireReference number:BTO-10-30
Using:warehouses,prisons,and in military fields
Factory,competitive price
CBT-65 Razor barbed wire hot-dipped galvanized barberd wire
Razor wire is also named concertina coils or razor type barbed wire.It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets.
Type:crossed razor barbed wire,single coil razor barbed wire,straight razor barbed wire,razor wire mesh fence.
Packing:pvc film inside,plastic bag outside,pvc film inside,hessian cloth outside
If you have any need of razor wire products,please feel free to contact us.
Specification as follow:
outside diameter | No.of loops | standard il | type
| notes
|
450mm | 33 | 8M | CBT-65 | Single coil |
500mm | 41 | 10M | CBT-65 | Single coil |
700mm | 41 | 10M | CBT-65 | Single coil |
960mm | 53 | 13M | CBT-65 | Single coil |
500mm | 102 | 16M | BTO-10.15.22 | Cross type |
600mm | 86 | 14M | BTO-10.15.22 | Cross type |
700mm | 72 | 12M | BTO-10.15.22 | Cross type |
800mm | 64 | 10M | BTO-10.15.22 | Cross type |
960mm | 52 | 9M | BTO-10.15.22 | Cross type |
Note:
Standard products are shown in the tables above, special specifications available on request.
Standard materials are either galvanized or stainless steel.
Our core wire made from high tensile galvanized steel wire (1500MPA),make the razor wire more rigid and difficult to cut.
| Razor Wire Concertina Specifications | ||||
| Outside Diameter | No. of Spirals | No. of Clips | Recommended Stretch Length | Notes |
| 300mm | 33 | 8-10M | Unclipped | |
| 450mm | 33 | 12-15M | Unclipped | |
| 600mm | 33 | 12-15M | Unclipped | |
| 300mm | 33 | 3 | 4M | Clipped |
| 450mm | 54 | 3 | 8-10M | Clipped |
| 610mm | 54 | 3 | 10-12M | Clipped |
| 730mm | 54 | 3 | 15-20M | Clipped |
| 730mm | 54 | 5 | 10-12M | Clipped |
| 980mm | 54 | 5 | 10-15M | Clipped |
