2-WE67Y Dual Link Hydraulic Press Brake1.Tandem control
2.Hydraulic drive
3.Combined by two press brake
4.With dies
2-WE67Y Dual Link Hydraulic Press Brake
Basic Principle:
1.This machine was combined by two sets of 400 tons press brake.
2.Tandem control achieve synchronous working. Single machine was combined by working table , right and left wall board.
3.Due to the transportation, we adopt assembled structure. The rack has strong rigidity, two cylinders were installed on right and left wall board, hydraulic system was under the action of electrical system, drive ram working down. On the ram, there are upper dies, when upper dies and lower dies touched, system will raise pressure and forming the workpieces.
4.With different dies and under different bending types, it can get different shapes of workpieces. The quality is stable and reliable.
Parameter:
SN |
Name |
Value |
Unit |
|
1 |
Nominal Pressure |
2*4000 |
kn |
|
2 |
Table Length |
2*8000 |
mm |
|
3 |
Max Slider Stroke |
250 |
mm |
|
4 |
Slider Max Opening Height |
810 |
mm |
|
5 |
Throat Depth |
800 |
mm |
|
6 |
Coil Thickness |
≤12 |
mm |
|
7 |
Main Motor Power |
2*22 |
kw |
|
8 |
Machine Size |
L |
16000(tandem) |
mm |
W |
2675 |
mm |
||
H |
4910 |
mm |
||
9 |
Machine Weight |
102000 |
kg |
|
Key Components:
SN |
Name |
Spec. |
Qty |
1 |
Oil Pump |
63 Above Displacement |
2 Sets |
2 |
Main Motor |
22 Kw |
2 Sets |
3 |
Adjust Motor |
1.1 k |
4 Sets |
4 |
Seals |
Full Set |
2 Sets |
5 |
Electrical Components |
|
2 Sets |
6 |
Hydraulic Valve Stack |
Dedicated System |
2 Sets |
7 |
Press Brake Cylinders |
Dedicated System |
2 Sets |
2-WE67Y Dual Link Hydraulic Press Brake :
If you interest in our products, please contact us, you will get the best reliable products by reasonable prices !
