Specifications
ZJP Electrostatic Powder Coating Line1.Heating:electric,coal,diesel,etc.
2.Long workpieces dedicated
3.Easy to operate
ZJP Electrostatic Powder Coating
Structural Features:
Room combined by cold-rolled steel sheet and assembly. Easy structure. Clean conveniently. Adopt side suction ventilation device and together with anti-dust lighting. Convenient for spraying.
Adopt assembly structure, outside with corrugated plates, oven is tight, solid, beautiful and with good insulation properties. Temperature use conventional electrical control, with the hot air circulation to ensure the uniformity temperature. Fully to meet 180°C±5°C powder curing requirements. It can spray surface of different light pole, signal pole, high mass pole. Also for dry processing. After spraying and drying, the surface is colorful, strong adhesion and durability.
Parameters:
SN |
Name |
Value |
Unit |
Remark |
|
1 |
Spray Length |
14 |
m |
Can Be Lengthened Or Shortened |
|
2 |
Max.Spray Pipe Diameter |
φ600 |
mm |
Can Increase |
|
3 |
Max.Spray Pipe Weight |
500 |
kg |
Can Increase |
|
4 |
Consume Power (Select One) |
Electric Heating |
180 |
kw/h |
User Must Select One Heating Type According To Their Local Energy |
Fuel Type |
22 |
kw/h |
|||
Coal-fired Type |
20 |
kw/h |
|||
Gas Type |
20 |
kw/h |
|||
5 |
Powder Curing Oven Dimensions |
L |
17000 |
mm |
|
W |
2100 |
mm |
|
||
H |
3200 |
mm |
The Highest Point |
||
6 |
Size Of Mobile Powder Room |
L |
4800 |
mm |
|
W |
1300 |
mm |
|
||
H |
2400 |
mm |
|
||
7 |
Machine Weight |
20500 |
kg |
|
|
Major Dispositions:
(1)power room
(2)high voltage electrostatic generator
(3)powder spraying system(four sets)
(4)powder pumping and recovery system
(5)0.5t hanging conveyor system(1 set)
(6)traversing car
(7)oven curing drying tunnel system(include electric heating,fuel type,coal type and gas type)
(8)electrical control system(1set)
ZJP Electrostatic Powder Coating :
| Model | ZDXB-6 | ZDXB-9 | ZDXB-12 |
| Milling perspective | 0-450 | 0-450 | 0-450 |
| Processing plate thickness | 6-50 | 6-50 | 6-50 |
| Milling hypotenuse of a maximum width | 20 | 20 | 20 |
| Milling hypotenuse of a maximum width | 1.2*7 | 1.2*11 | 1.2*1.5 |
| Hydraulic pressure | 1.5 | 1.5 | 1.5 |
| Feed motor power | 1.1/1.5 | 1.1/1.5 | 1.1/1.5 |
| Milling motor power | 2.2/3 | 2.2/3 | 2.2/3 |
| Pump motor power | 3 | 5.5 | 5.5 |
| External dimensions | 7820*2240*1950 | 10820*2240*1950 | 16820*2240*1950 |
ZJP Electrostatic Powder Coating:
If you are interest in our products or our services, please contact us, you will get the best reliable products in reasonable prices !
