Specifications
Agricultural Irrigation Diesel Water pipe1.Get state approved patent certificate
2.Can be retrieved easily
3.Multi usage
Agricultural Irrigation Diesel Water pipe
Advantage:
1. Get state approved patent certificate
2. Water duct is connected with bypass by mosaic, bypass is connected with capillary tube to distribute the water in the water pipe.
Simple structure, convenient to install and dismantle, high connecting efficiency for the water duct and capillary tube, saving installation time;
Water duct can be retrieved easily and reused with high economic benefits
3. Water duct is locked and sealed up with bypass or end cap by patch, or by pad of bypass and seal groove itself, with good sealing effect
4. For the new type water pipe and assembly, the via hole has inside screw structure and the bypass and end cap has external thread that can be compatible with inside screw
5. End cap can be installed to plug the via hole if the bypass is no need, water delivery net can be arranged according to the requirement
6. To save water and make the limited water in good use
Parametric:
The parametric of PE Composite Water Pipe |
|||||||||
Type |
Max. working pressure ( bar ) |
Thickness of the pipe wall |
Internal diameter (mm) |
Fold diameter (mm) |
|||||
Diameter |
Common |
Strengthen |
StrengthenⅡ |
Common |
Strengthen |
StrengthenⅡ |
|||
50mm |
3.5bar |
4.5 bar |
5bar |
0.4mm |
0.6 mm |
0.7 mm |
50 mm |
80.7 mm |
|
63mm |
3.25 bar |
4.25 bar |
4.75bar |
0.4 mm |
0.6 mm |
0.7 mm |
63 mm |
101.2 mm |
|
75mm |
3 bar |
4 bar |
4.5bar |
0.4 mm |
0.6 mm |
0.7 mm |
75 mm |
120.6 mm |
|
90mm |
2.75 bar |
3.5 bar |
4bar |
0.4 mm |
0.6 mm |
0.7 mm |
90 mm |
142 mm |
|
100mm |
2.5bar |
3 bar |
3.5bar |
0.4 mm |
0.6 mm |
0.7 mm |
100 mm |
161.5 mm |
|
110mm |
2.25bar |
2.75 |
3.25bar |
0.4 mm |
0.6 mm |
0.7 mm |
100 mm |
178.1mm |
|
Accessories:
Plan A:
Plan B:
Plan C:
Plan D:
