China Acrylic Wood engraving cnc router machine with 3KW spindle
1. Parameters
| Name | Type-A wood cnc router machine |
| Dimension | 2900mm*1885mm*1660mm |
| Netto Weight | 950kg |
| Voltage | AC 220V |
| Power | 3.0kw |
| Working Area | 1300mm*2500mm*200mm |
| Working precision | <0.05/300min |
| Max. cutting speed | 8m/min |
| Max. engraving speed | 8m/min |
| Input order | G code |
| Spindle | Water cooling spindle with 3 kw/4.5kw power |
| Spindle RPM | 6000-24,000rpm |
| Shank diameter | 3.175/6.0/12.7 |
| Driver | Shenzhen RCON driver |
| Motor | Shenzhen RCON step motor |
| Frequency converter | Shenzhen Sunfar |
| Dust collection device | 3.0kw binocular |
| Control system | Ncstudio |
| Support software | cnc engraving software,CAD,CorelDRAW,Type3 |
| Rack type | Imported from Germany |
| Guide rail | 20mm linear square rail |
| Warranty | 1 year, not including consumable itemd like knife tool and collet |
2. Application:
- Widely used in making and processing sign, nameplate, acrylic-cutting, plastic moulding and large cutting, all kinds of wooworking products, photo frame, craftwork, etc.
- Also applied to engraving iron, alu, plastic plate, wood and other metallic/non-metallic materials.
3. Features
- Intelligent protection against scratches on working table and mechanical impact, when desighed area exceed the working area
- Whole-iron-welded lathe bed, aging treatment gurantees no deformation
- Double motor driver on Y-axis gurantees stable movement
- High-precision gear rack transmission ensures high speed and accuracy
4. Advantages
- Speedy processing: same speed for curve and straight line, max travel speed reaches 20m/min.
- Big storage room: support direct output from USB-stick with storage room up to 4 Gegabyte.
- Two control modes:1. Ncstudio with internet, one PC controls several equipments at the same time. 2. Off-line control with hand grip and RJ 45 pattern interface.
- Compatibility of various files: Type3, ArtCAM, Casmate, CAXA, etc.. High support rate of G- and IJK-code.
- Multi-functional operation: breakpoint restore function, continued engraving from breakpoint, automated emendation, resharpen, parking position setting and positioning with up to 9 coordinates.
Warranty
1.One year quality guaranty, the machine with main parts(excluding the consumables)
2.With lifetime maintenance
3.Free training course at our company
After-sale Service
a)Engineer available to serve machinery overseas
b) All the machines will be tested and adjusted as per requirements before shipping.
c) On-site training service provided.
We can offer one stop advertising equipment.
More products, pls click products categories.
Please let us know the follow information when enquiring:
Q: How about after-sales service?
A: 1. We can provide free training in our Foshan factory or Guangzhou office.
2. If u need, our engineers are available to service machinery overseas. But u need pay the tickets and hotel fees for our engineers.
Q: How about the warranty?
A: One year warranty. Spare parts are not included. We suggest u buy some spare parts in stock.
Q: What should I do when I have some problems or questions?
A: Pls don’t hesitate to contact us via Skype, WhatsApp, Viber or email, we will reply u ASAP. If u are not satisfied with someone’s service, u can complain to our Boss.
Q: How about the quality?
A: Before we pack each machine, we will test it first. If machine has problem in your place, our worker will take responsible for his mistake. And we will solve your problem.
Q: Which is the most suitable model machine for me?
A: Pls tell us your materials, thickness, size and business industries.
