cem-1 copper clad laminated sheet for sale
- 500 Sheet / Sheets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
- 3240 Epoxy Board, High-quality Insulation Material, Flexible Customization, Widely Applicable 3240 Epoxy Sheet
- Chinese Factory Electrical Insulation Brown 3025 Phenolic Bakelite Resin Cotton Cloth Fabric Laminate Board Sheet Phenolic Board
- 4x8 fiberglass sheets g10 epoxy glass fiber board g10 material
- Factory Price Bakelite Decorative HPL Press plates bakelite sheet
- Black G10 Sheet - High Quality Carbon Fiber G10 FR4 Sheets - Precision-made PCB Materials
Product Details
Place of Origin: | Anhui, China | Brand Name: | Hero Sail | Model Number: | HR-1130 |
Type: | Insulation Sheet | Material: | Fiberglass | Application: | High Temperature |
Product Description
Specifications
1.UL,VDE,SGS,CQC,TS16949,MSDS,RoHS2.Price for cem-1 copper clad laminated sheet
3.Excellent punching&machining property
CEM-1 copper clad laminated sheet
Application:
HR1130 laminate sheet widely used in
monitor,
power supply,
keyboard,
game machine,etc.
Standard size
Base Color | Thickness | Copper Clad | Regular Size | Thickness |
white yellow | 0.8~1.6mm | H oz(18μm) 1oz (35μm) 2oz (70μm) | 915×1220mm(36″×48″)1020×1220mm(40″×48″) 1070×1220mm(42″×48″) | IPC4101C C/M |
Desciption:
HR-1130 Laminate | Unit | specification | Typical Value | Test Method | |
Metric | <0.5mm | ≥0.5mm | 1.6mm CCL | IPC-TM-650 | |
1. Peel Strength,as received. | N/mm | 1.8 | --- | ||
A. 17micron copper | ≥1.05 | ≥1.05 | |||
B. 35micron copper | ≥1.4 | ≥1.4 | |||
C. 70micron copper |
|
| |||
D. 105,140,175micron copper and above |
|
| |||
2. Surface resistivity | MΩ | ||||
A. Constant temp.&moisture C-96/35/90 | ≥103 | --- | --- | ||
B. After moisture resistance | --- | ≥103 | 2.7×106 | ||
C. Under high temperature | ≥103 | ≥103 | --- | ||
3. Volume resistivity | MΩ.cm | ||||
A. Constant temp.&moisture C-96/35/90 | ≥103 | --- | --- | ||
B. After moisture resistance | --- | ≥103 | 2.9×106 | ||
C. Under high temperature | ≥103 | ≥103 | --- | ||
4. Moisture absorption | % | --- | ≤0.80 | 0.11 | |
5. Dielectric breakdown | KV | --- | 40 | 45 | |
6. Permittivity at 1MHZ | -- | <5.4 | <5.4 | 4.6 | |
7. Tg(DSC) | °C | --- | --- | 110 | |
8. Loss tangent at 1MHZ | -- | <0.035 | <0.035 | 0.026 | |
9. Thermal stress | 260°C/10S | ||||
Non-etching | pass | pass | pass | ||
Etch | pass | pass | pass | ||
10. Flammability | Rating | 94V-0 | 94V-0 | 94V-0 | |
11. Flexural strength of laminate | N/mm2 | ||||
Length direction | --- | ≥242 | 410 | ||
Cross direction | --- | ≥172 | 280 |
Details:
FAQ
Q: 1. Can I have free samples?
A: Yes, we can provide free sample only for small size after you accept our price and all the information confirmed by you.
Q: 2. What is the manufacturing time?
A:Sample needs 1-3 days, mass production needs 7-10 days, It depends on quantity.
Q: 3. What is your MOQ?
A: Our MOQ is 300 sheets for copper clad laminate,and 300 meters of prepreg
Q: 4. Can you accept mixed batch of different products?
A: Yes, we are support different product mix wholesale.
Q: 5. How do you ship the goods ?
A: For huge quantity,we can deliver it by FCL,for small quantity,we can deliver by LCL,samples will deliver by DHL,FEDEX,UPS,etc.
Any other question,pls feel free to leave a message.We are looking for your inquiry!
