solar cable 6mm1) TUV 2pfg 1169
2)2.5/4.0/6.0/10mm
3)black,red,blue
solar cable 6mm
SPECIFICATION OF SOLAR CABLE
1. Construction
Cross Section | Conductor Construction | Conductor nominal Dia | Standard diameter | Outer diameter |
mm2 | pcs/mm |
| mm | mm |
1*1.5 | 30/0.25 | 1.57 | 3.38±0.1 | 5.5±0.2 |
1*2.5 | 50/0.25 | 2.02 | 3.38±0.1 | 5.5±0.2 |
1*4.0 | 56/0.30 | 2.59 | 4.29±0.1 | 6.1±0.2 |
1*6.0 | 84/0.30 | 3.56 | 4.87±0.1 | 7.0±0.2 |
1*10 | 80/0.40 | 4.75 | 5.93±0.1 | 8.3±0.2 |
1*16 | 128/0.40 | 5.84 | 7.02±0.1 | 9.4±0.3 |
1*25 | 196/0.40 | 7.30 | 8.7±0.1 | 11.1±0.3 |
CONDUCTOR MATERIAL: Tinned coper
INSULATION MATERIAL: Electron-beam cross-linked
COLOR: BLACK,RED BLUE OR CUSTOMIZED
2. Technical Data
Nominal voltage: U/U=600/1000 AC, 1800DC
Test Voltage: 6500V, 5min, 50Hz
Conductor DC resistance at 20°C≤ 3.39Ω/km
Temp. rating: -40°C~+125°C
Max. Conductor Temp.: +120°C
Ambiet Temp. (-40°C~+90°C): >25 years
Bending radius: ≥8×cable OD
Fire performance: IEC60332-1 TUV 3Pfg1169/08:2007
UV Resistant ≥720h
Content of halogen acid gas: IEC670754-1 EN50267-2-1
Smoke density: IEC61034, EN50268-2
