Open Frame Lovol Generator Set

Name: Open Frame Lovol Generator Set
Brand: hiearns
SKU: 104241585
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

hiearns

Model Number:

GF1-90KVA

Changzhou Hi-Earns Mechanical & Electrical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name hiearns

Model Number GF1-90KVA

Output Type AC Three Phase

Speed 1500rpm/1800rpm

Frequency 50hz/60hz

Rated Power 87.5KVA/70KW

Specifications

Lovol generator set
1)open frame,Lovol engine,stamford alternator
2)low fuel consumption,bigger fuel tank
3)good sevice

Lovol generator set

Engine Data
Manufacturer/Model:				Lovol(Tianjin) / 1006TG1A
Air Intake System:				4 Cycle,Turbocharger
Fuel System:				Direct Injection Fuel System
Cylinder Arrangement:				6 in line
Displacement:				5.99L
Bore and Stroke:				100×127(mm)
Compression Ratio:				17.5
Rated RPM:				1500rpm
Max.Standby Power at Rated RPM:				84.3KW
Governor Type:				Mechanical
Steady State Frequency Regulation:				±0.5%
RPM of Piston:				6.35m/s
Exhaust System
Exhaust Flow:				15.56m3/min
Exhaust Temperature:				545°C
Max Back Pressure:				6kPa
Air Intake System
Max Intake Restriction:				5kPa
Buring Capacity:				5.74m3/min
Intake Flow:				115m3/min
Fuel System(Fuel Consumption)
100% Standby Power Load:				21.4L/h
100% Prime Power Load:				19.2L/h
75% Prime Power Load:				L/h
50%(Prime Power) Load:				L/h
Total Fuel Flow:				L/h
Lubricating Oil System
Total Oil Capacity:				19L
Oil Pan Capacity:				16L
Oil Pressure at Rated RPM:				300~340kPa
Cooling System
Total Coolant Capacity:				27.7L
The Highest Temperature:				100°C
Coolant Flow:				138L/min
Electrical System
System Voltage(Starter Voltage):				DC 24V
Rated Current for Charge Alternator:				A
Optional Parts

Engine: Oil Heater / Battery Charger 3.5 & 7A
Alternator: Alternator Heater
Control System: Remote Control Panel / Auto Transfer Switch(ATS) / Paralleling System
Others: Spare Parts / Tools / Daily Fuel Tank
