125KHz RFID Gym Digital Locker Lock

Product Specification

Model Number

1080D

Brand

EDA

Multiple Function Mode

1. Model 1080D-D:  Digital Only

2. Model 1080D-E:  RFID Card + Digita

3. Model 1080D-F:  Free Choice Function Mode

Card Type

EM4100/4305, 125KHz

Card Size

RFID Tag, RFID Key fob, RFID Wristband

Keypad

Material: Zinc Alloy

Size: 55x108x8MM

Net weight: 220g

Color: Sliver, Gold, Black & other colors available

Lock Body

Multiple Function Mode

1. LB-01

Material: Stainless Steel Anti-thief Lock Body

Size: 105x60x22MM

Net Weight: 50g

Color: Sliver le

Battery: 4PCS AAA Standard Battery

2. LB-02

Material: Plastic Anti-thief Lock Body

Size: 61x110x23MM

Net Weight: 100g

Color: Grey, Blue & other colors available

Battery: 4PCS AAA Standard Battery

3. LB-03

Material: Plastic Classic Lock Body

Size: 138x67x24MM

Net Weight: 80g

Color: Blue, Grey & other colors available

Battery: 3PCS AA Standard Battery

Power Supply

DC4.5V, use of 4 pieces of AAA batteries, Or 3PCS AA Standard Battery

Battery Life

5000 to 8000 openings

Supply Voltage

Below DV4.5V with lack of voltage indications and can use about 200 more times.

Static Power Supply

<10u A

Dynamic Power Supply

<150mA

Lifetime of Battery

Normally can exceed 8000 times and 200 more with low energy indication

Latch Length

15mm

Door Thickness

10-35mm(Additional solution for less thickness application available)

Working Temperature

-20~+55

Working Humidity

0~98%

Management Level.

4 Levels

Incorrect Code Alarm

YES

Master Key

YES

User Key

YES

Master Code

YES

One-Time-Code

YES

Code Setting

1 to 9 numbers (From number buttons 0~9)

Blue LED Usage

Indicator

YES, blue light flashing every 3 seconds if lock has been occupied

Fault Tolerant Input

YES

Illegal Key Alarm

YES

Anti-thief alarm(ATA)

YES

Low-Voltage Alarm

YES

External Power Backup

YES

Anti-moisture

YES

Anti-dust

YES

Anti-shock

YES

Replacing the Battery Easy

YES

Whole life Maintenance

YES

Warranty

2 years

Inner Package

EPE foam sheet per lock part

Inner Box

White Box

Size: 145x116x75MM

Weight: N.W./G.W.: 610g/620g,

Outer Carton

Carton Box

Size: 440*350*280MM

Weight: N.W./G.W. 24.5KGS/25KGS

Volume: 0.0435CBM

Other solutions available according to customer's requirements

Test Process Control

5-Point 100% Inspection

Certification

CE,RoHS,FCC, ISO

Features

1. Application Fields: Gym, Spa, Health and Fitness clubs, Golf, Swimming Pool, Sauna, Athletic locker rooms,

     Schools, Colleges and Universities, Hotels, and Office

2. Outer shell is made of extra good quality metal material, which is painted by powder-spray craft work.

3. This lock is special designed, with every aspect of environment and operation impacts the experience your facility provides.

4. Multiple lock body & management solutions, interface, function and latch options to match your facility’s application.

5. Fault Tolerant Input function, any incorrect digits code can be input before inputting the correct code

6. Free Choice Function available for public storage solution application.

7. Different Color is available with Black, Shinning-silver, Black, Golden, Color Is Optional.

8. OEM/ODM available, Customer’s logo printed available.
