Specifications
Conveyor Belt Vulcanizing press1.100% real Factory
fessional for vulcanizer 23years
3.CE SGS
4,Good service
Rubber Conveyor Belt Press Conveyor Belt Vulcanizing Press With CE SGS
Product Description
Conveyor belt vulcanizing press is adopt for modern frame structures, the platen and plunger are all made of superior material, they are accuracy processed and have high wear-resistance.
The features are as follow: convenient maintenance, smotiaothly-operation, easy-adjusted ,The plcam control system can realize multi program automatic control of curing process, the temperature of the platen can be measured and regulated. And is a synchronous axis under the platform. This will improve the control level and provide with high efficiency of production and low intensity of labor.
Technical Parameters
Model | XLB-1100*5700 | XLB-1400*5700 | XLB-1400*10000 | XLB-1600*8500 | XLB-1600*10000 | XLB-2000*10000 |
Plate size | 1100*5700 | 1400*5700 | 1400*10000 | 1600*8500 | 1600*10000 | 2000*10000 |
Total pressure | 17.55MN | 25.00MN | 49.00MN | 47.60MN | 56.00MN | 70.00MN |
Plate pressure | 2.8 Mpa | 3.13 Mpa | 3.5 Mpa | 3.5 Mpa | 3.5 Mpa | 3.5 Mpa |
Diameter of piston | 500 mm | 360 mm | 450 mm | 500 mm | 450 mm | 600 mm |
Piston number | 5 | 10 | 20 | 14 | 18 | 16 |
Piston stroke | 520 mm | 400 mm | 300 mm | 300 mm | 400 mm | 300 mm |
Working layer | 2 | 2 | 1 | 1 | 2 | 1 |
Clamping force | 0.50 | 0.72 | 0.90 | 0.6 | 1.20 | 1.20 |
Drawing force | 0.40 | 0.60 | 0.80 | 0.5 | 1.10 | 1.00 |
Steam pressure | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa | 0.63 Mpa |
Cooling pressure | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa | 0.3 Mpa |
Operation system | PLC | PLC | PLC | PLC | PLC | PLC |
Application | nylon rope belt conveyor, PVG/fabric such as core parallel tape. | |||||
We can also design and produce according to customer's demand .
Picture Show
