Home > Products > Lamp&Appliance&Curtain Module > TAIYITO TDXE4404/4202/4203 Remote Control Bidirectional Light/Appliance Module/x10 module
TAIYITO TDXE4404/4202/4203 Remote Control Bidirectional Light/Appliance Module/x10 module
- 10000 Piece / Pieces per Month
- Tianjin/Ohers
- Credit Card
- TAIYITO TDXE4404 Bidirectional X10 Light Module/Remote Control x10 module
- X10 Home Automation Water Heater Module
- X10 Home Automation Module Remote Control
- TDXE4401 Home Automation System Module Remote Control Dimmer Light
- TDXE4401 Home Automation System Dimmer Light Module
- TDXE4401 1 Gang Dimmer Light Module Smart Home Automation
Product Details
Place of Origin: | Tianjin, China | Brand Name: | TAIYITO | Model Number: | TDXE4203/4404/4202 |
Packaging Details
Paper box for x10 module, Net Weight(g):60g, package size:80*77*40mm/pc, product size:46*46*23mm/pc
Product Description
Specifications
1.TAIYITO TDXE4404/4202/4203 Remote Control Bidirectional Light/Appliance Module/x10 module2.PLC/x10 module
3.lamp module
TAIYITO TDXE4404/4202/4203 Remote Control Bidirectional Light/Appliance Module/x10 module
x10 module Series:
TDXE4202 Appliance x10 module( Max 2200W)
TDXE4401 Incandescence Lamp Micro x10 module
TDXE4203 Fluorescent Lamp x10 module(Max1500W)
TDXE4404 2-way Fluorescent Lamp/Appliance x10 module
TDXE4602 2-Way Scene x10 module( Used with max 4-Button Switch Panel)
TDXE4466 Curtain Controlling x10 module
X10 Module Specification:
Product Description | Micro Lamp/Appliance x10 module | Curtain x10 module | Scene x10 module | |||||
Model No. | TDXE4202 | TDXE4401 | TDXE4203 | TDXE4404 | TDXE4466 | TDXE4602 | ||
Commands | All On |
| Yes | Yes | Yes | Yes | Yes | |
All Off | Yes | Yes | Yes | Yes | Yes | Yes | ||
Dimmer |
| Yes |
|
|
|
| ||
Specs | Voltage&Frequency | 220VAC±10%,50Hz | ||||||
Maximum Load | 2200W | 300W | 300W | 600W | 45W |
| ||
Controllable Device | Appliance | Incandescence | Fluorescent&Appliance | Curtain | x10 modules |
| ||
Neutral Wire | yes | |||||||
Operating Temp | -10-50°C | |||||||
Static Power | <0.5W | |||||||
Dimension(W*H*D) | 46*46*23mm | |||||||
Response Time | ≤2s | |||||||
Features:
Bidirectional communication by power line in high speed with the feedback function
Connect with any type of switches, and plug-in panel
Ultra-slim design.
Dimension: 46x46x23mm
Easy to use and setup. Can finish address code learning within 6 seconds.
Use noise filter circuit inside
Commands all on/off for lamps
Command all off for electronic appliances
• x10 module---CE Certification
Terms&Warranty
1.We provide 1 years warranty.
2.If the item is defective use by technical reason,you could sent back to us for New one.
3.All items must be returned in their original condition.In order to qualify for a refund or exchange of goods.
4.Items returned after 7 days of delivery are only eligible for repair.
5.The buyer is responsible for all shipping costs incurred.
6.No refund accepted after 30 Days of receipt.
7. After receipt of the goods found any questions, please contact us solve the problem
Shipment
1.Items are only shipped after payment is received.
2.We provide DNJ,EMS,DHL ,TNT for shipping method.
3.Delivery time:
EMS,UPS,DHL,Fedex and TNT express shipping usually take 3-7 working days depends on the country delivered to.In rare cases,the strict custom clearances will make the delivery time a bit longer,please be patient.
4.We are not responsible for any accidents,delays or other issues which are the responsibility of the shipping service.
5.Any import charges or fees are the buyer’s responsibility.
6.Please check out your ADDRESS carefully when processing order.
7.Feel free to Contact us with any question,we will offer you satisfying answer.
Contact Informaiton
Company Profile
Taiyito Design Center of Taiyito Technology was founded in 2006 and is constituted of some hardware and software R&D engineers who have 5 or 6 years' experience in electric product design in the intelligence field. Comparing with smart products at home or abroad and being compatible with advanced technology and experience of smart home control, based on embedded computer system, Tianjin Taiyito Technology Co., Ltd. has devoted to smart home technology, communication technology and computer technology for stable bi-direction communication. We regard the manufacture and technology of products, which are first class and can meet customers' requirement, as our responsibility.
Taiyito Design Center has efficient and precise organization; clear and reasonable R&D processes; normative and canonical methods for outdated, and inspection and testing. We have senior engineers who have about ten years' experience in the electron industry field and many years in the smart home field, as well as in the machine, structure, mould, software, hardware, technology, and process fields. We have particular view for material selection, canonical and scientific process and assembly. R&D design electro circuit is our proud specialty. Engineers of Taiyito Design Center can complete product manufacture under the purpose of high-speed, high-efficiency and high-quality, whether the work is from simple module electro circuit to complicated radio frequency and coding & decoding electro circuit, or simple single chip micyoco (SCM) software program to complicated huge embedded system.
Tianjin Taiyito Technology Co., Ltd cooperated with Tianjin Electrical Component Group Third Component Company to exert both special advantages: specious and ordering jointing process workshop; well-trained and high-efficient management team and staff, who regard quality weightier than Mount Tai; precise, unified and advanced process instrument and equipment; canonical, scientific and normative technical process; conscientious and meticulous operating system and quality standard; passed relative quality standard and quality authentication many times. All these above measures can ensure high-quality and high-output millions of electrical products monthly.
Taiyito Design Center and manufacture process institution regard creating international advanced smart home technology as target, and develop towards this realizable target step by step. We are devoted to make people living more niceness and fashion.
