Frozen Vegetables Color Sorter

Specifications

• Features:
  .

  1.Full color CCD camera :High resolution with 2048 pixels, within definition up to 0.08 square millimeter.

  2.Real time display of actual material image: Real material image can be seen in the surface of the controlling computer.

  3. Self-designed computer controlling system: Fully digital processing keeps a high sorting accuracy.

  4. LED light source: with uniform color and long life.

  5. Advanced high-accuracy valve and nozzle: achieve 1000 shoots per second theoretically.

  6.Belt transmission: uniform and stable belt conveyor speed making small collision and low damage ration for materials.

  Product features:

  • High-Definition and high-sensitivity chromatic CCD image sensor, together with industrial wide-angle lens for accurate recognition;
  • Adopt the international first-class optical lens; the articulation up within 0.07 mm2 can recognise a subtle chromatism and tiny flaws.
  • By using high-speed parallel data processing chip, real-time efficient image acquisition and processing system, greatly improving the color separator working efficiency.High quality image processing algorithm:
  • Adopt international advanced image processing technology, can effectively identify small to 0.1 mm of tiny impurities, color choose higher accuracy, color choose than lower brought out.
  • Convenient computer operating system, could save many different sorting mode for clients in order to suit different materials.
  • Unique LED lighting system, Equipped with LED light source, and to ensure the high-definition image quality, can meet 1000 kinds of color separation, identify color changes.
  • Fan self-adaptive working temperature, ensure color separator in the high temperature environment also can work normally.
  • The incomparable eliminate accuracy, more perfectly sorting out finished with a defective; high resolution, big material nozzle; High frequency, long durability and long service life.
  • Easy for clients to install in factory. Unique double layer belt-type design could finish all the processing procedure at one time, and only need one elevator.



  Type		AL1K2C8-128/256
  Channels		128/256
  Output(t/h)		1-4
  Sorting accuracy (%)		>99.98
  Optimized carryover(bad :good)		9/1
  Voltage (V)		~220(50Hz)
  Power of main machine (kW)		2.0
  Air Pressure (MPa)		0.6~0.8
  Dimension(L*W*H)(mm)		2730*1820*1580
  Weight (kg)		950

  Note: The above properties of color sorting of frozen vegetables (2% impurity), for example, specific indicators for material,size, impurity content varies.

 Please feel free to contact us if more information is needed.
