NMRV050 Motovario Like RV Series Aluminium Alloy Worm Speed Reducer
- Shanghai Ningbo
- T/T Credit Card
You May Like
-
NMRV040 Motovario Like RV Series Aluminium Alloy Worm Speed Reducer
-
NMRV030 Motovario Like RV Series Aluminium Alloy Worm Speed Reducer
-
NMRV025 Motovario Like RV Series Aluminium Alloy Worm Speed Reducer
-
NMRV090 Aluminium Speed Reducer, Gearbox Spare Parts
-
NMRV090 Aluminium Speed Reducer, Packing Machinery Gearbox,packing Machinery Spare Parts
-
NMRV090 Aluminium Speed Reducer, Printing Machinery Spare Part
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Chenxin | |
| Model Number | NMRV020-150 | Gearing Arrangement | Worm | |
| Output Torque | 2.6-1195N.M | Rated Power | 0.06KW/0.09KW/0.12KW/0.18KW | |
| Input Speed | 1400rpm | Output Speed | 14-280rpm |
Product Description
Characteristics:
(1)Large output torque
(2) Safe, reliable, economical and durable
(3) Stable transmission, quiet operation
(4)High heat-radiating efficiency, high carrying ability
(5) Combination of two single-step worm gear speed reducers, meeting the requirements of super speed ratio
Technical data:
(1) Iput power:0.06kw-15kw
(2) Output torque:4-2320N.M
(3) Speed ratio: 5/10/15/20/25/30/40/50/60/80/100
(4) With IEC input flange: 56B14/71B14/80B5/90B5…
Materials:
(1) NMRV025-NMRV090: Aluminium alloy housing
(2) NMRV110-150: Cast iron housing
(3) Bearing: NSK bearing & Homemade bearing
(4) Lubricant: Synthetic & Mineral
Color:
(1) Blue / Light blue
(2) Silvery White
Quality control
(1) Quality guarantee: 1 year
(2) Certificate of quality: ISO9001:2000
(3) Every product must be tested before sendingv
