2016 10.1 Inch TFT Module 1280*800 With 8bit*LVDS Interface and High Resolution

2016 10.1 Inch TFT Module 1280*800 With 8bit*LVDS Interface and High Resolution photo-1
2016 10.1 Inch TFT Module 1280*800 With 8bit*LVDS Interface and High Resolution photo-2
2016 10.1 Inch TFT Module 1280*800 With 8bit*LVDS Interface and High Resolution photo-3
US$ 1 - 99 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ANSTAR
Model Number:
AS101NA-02C-C
Payment & Shipping
Payment Methods:
Port of Shipment:
HONGKONG
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name ANSTAR
Model Number AS101NA-02C-C
Type TFT
Product Description
Item
AS101NA-02C-C
Screen Size
10.1
Module Size(WxHxD,mm)
229.46X149.1X2.8
Active Area(mm)
216.96X125.6
Display Mode
Normally White,Transmissive
Display colors
16.7M
Resolution
1280x3(RGB)x800
Viewing Angle (Tpy.)θT/θB/θL/θR
75/70/75/75
Aspect Ratio
16:10
Luminance(nits)
200
Contrast Ratio
700
Power Consumption (W)
TBD
Interface
8bit*LVDS
connecting type
40pin FPC
Operation Temperature( ℃)
-20~60
Storage Temperature (℃)
-30~70
HTHH.(op)
40℃,90% RH
Response Time(ms)
30
Dot Pitch(WxH,mm)
0.0565X0.1695
