1. Overview
The industry-standard Cisco® Small Form-Factor Pluggable (SFP) Gigabit Interface Converter is a hot-swappable input/output device that plugs into a Gigabit Ethernet port or slot, linking the port with the network (Figures 1, 2 and 3). SFPs can be used and interchanged on a wide variety of Cisco products and can be intermixed in combinations of 1000BASE-T, 1000BASE-SX, 1000BASE-LX/LH, 1000BASE-EX, 1000BASE-ZX, or 1000BASE-BX10-D/U on a port-by-port basis.
Figure 1. Cisco optical Gigabit Ethernet SFP
Figure 2. Cisco 1000BASE-T Copper SFP
Figure 3. Cisco 2-channel 1000BASE-BX optical SFP
1000BASE-ZX SFP for Long-Reach Single-Mode Fibers
The 1000BASE-ZX SFP operates on standard single-mode fiber-optic link spans of up to approximately 70 km in length. The SFP provides an optical link budget of 21 dB, but the precise link span length depends on multiple factors such as fiber quality, number of splices, and connectors.
When shorter distances of single-mode fiber (SMF) are used, it might be necessary to insert an inline optical attenuator in the link to avoid overloading the receiver. A 10-dB inline optical attenuator should be inserted between the fiber-optic cable plant and the receiving port on the SFP at each end of the link whenever the fiberoptic cable span loss is less than 8 dB.
--------------------------
2. Item Number: GLC-ZX-SM
Description: 1000BASE-ZX extended distance
Data Transfer Rate : 1Gbps
Condition: New Sealed
Waranty: 1 Year
| General | |
|---|---|
| Device Type | SFP (mini-GBIC) transceiver module |
| Enclosure Type | Plug-in module |
| Width | 1.3 cm |
| Depth | 5.7 cm |
| Height | 0.9 cm |
| Weight | 75 g |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Features | Hot swap module replacement |
| Compliant Standards | IEEE 802.3z |
| Manufacturer Warranty | |
| Service & Support | 90 days warranty |
| Service & Support Details | Limited warranty - 90 days |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 70 °C |
| Compatibility Information | |
| Designed For | Cisco 3825 Integrated Services Router Branch Office in a Box Bundle, 3825 Integrated Services Router Secure WAN Optimization Bundle, 3825 Integrated Services Router WAN Application Acceleration Bundle, 3825 Integrated Services Router WAN Optimization Bundle, 3825 Voice Security Bundle, 3845 Integrated Services Router Branch Office in a Box Bundle, 3845 Integrated Services Router WAN Application Acceleration Bundle, 3845 Integrated Services Router WAN Optimization Bundle, 3845 Secure WAN Optimization Bundle, 3845 Voice Security Bundle, 7301 ITP Signaling Gateway Bundle, 7301 VAM2+ Router Security Bundle ¦ Cisco ASA 5545-X Firewall Edition, 5545-X IPS Edition, 5555-X Firewall Edition, 5555-X IPS Edition ¦ Cisco Catalyst 2960-24LC-S, 2960-24PC-L, 2960-24PC-S, 2960-24TC, 2960-24TC-L, 2960-24TC-S, 2960-48PST-L, 2960-48PST-S, 2960-48T, 2960-48TC, 2960-48TC-L, 2960-48TC-S, 2960-8TC, 2960-8TC-S, 2960G-24TC, 2960G-48TC, 2960G-8TC, 2960S-24PD-L, 2960S-24PS-L, 2960S-24TD-L, 2960S-24TS-L, 2960S-24TS-S, 2960S-48FPD-L, 2960S-48FPS-L, 2960S-48LPD-L, 2960S-48LPS-L, 2960S-48TD-L, 2960S-48TS-L, 2960S-48TS-S, 2970G-24TS-E, 3560-12PC, 3560-12PC-S, 3560-24TS, 3560-24TS EMI, 3560-24TS SMI, 3560-48TS, 3560-48TS EMI, 3560-48TS SMI, 3560-8PC, 3560E-12D, 3560E-12SD-E, 3560E-12SD-S, 3560E-24PD, 3560E-24TD, 3560E-48PD, 3560E-48PD-F, 3560E-48TD, 3560E-48TD-SD, 3560G-24PS EMI, 3560G-24PS SMI, 3560G-24TS EMI, 3560G-24TS SMI, 3560G-48, 3560G-48PS EMI, 3560G-48TS EMI, 3560V2-24PS, 3560V2-24TS, 3560V2-24TS-SD, 3560V2-48PS, 3560V2-48TS, 3560X-24P-L, 3560X-24P-S, 3560X-24T-L, 3560X-24T-S, 3560X-48PF-L, 3560X-48PF-S, 3560X-48P-L, 3560X-48P-S, 3560X-48T-L, 3560X-48T-S, 3750-24FS, 3750G-12S, 3750G-12S-S, 3750G-24PS-E, 3750G-24PS-S, 3750G-48PS-E, 3750G-48PS-S, 3750G-48TS-E, 3750G-48TS-S, 4500 Series Supervisor Engine V-10GE ¦ Cisco Catalyst Express 500-24LC, 500-24PC, 500G-12TC ¦ Cisco ME 2400-24TS, 3400-24TS, 4924-10GE, 6524 Ethernet Switch |
--------------------------
3. Our Services
==>Trusted by 5000+Worldwide Buyers
==> Huge Inventory in Stock
==>Up to 1 Year Warranty
==>Save up to 50%-98% off GPL
==>Cisco Certified Internetwork Expert Support 7X24 Hours
==>Flexible Payment & Shipment
==>100% Money Bank Guarantee
--------------------------
4. Related Products
-------------------------------
Product Number |
Product Description |
GLC-T |
1000BASE-T standard |
GLC-SX-MM |
1000BASE-SX short wavelength; without DOM |
GLC-LH-SM |
1000BASE-LX/LH long-wavelength/long haul; without DOM |
GLC-ZX-SM |
1000BASE-ZX extended distance |
GLC-BX-D |
1000BASE-BX10-D downstream bidirectional single fiber; with DOM |
GLC-2BX-D |
2-channel 1000BASE-BX10-D downstream bidirectional single fiber; with DOM |
GLC-BX-U |
1000BASE-BX10-U upstream bidirectional single fiber; with DOM |
SFP-GE-T |
1000BASE-T NEBS 3 ESD |
|
SFP-GE-S GLC-SX-MMD |
1000BASE-SX short wavelength; with DOM |
|
SFP-GE-L GLC-LH-SMD |
1000BASE-LX/LH long-wavelength; with DOM |
GLC-EX-SMD |
1000BASE-EX long-wavelength; with DOM |
SFP-GE-Z |
1000BASE-ZX extended distance; with DOM |
GLC-SX-MM-RGD |
1000BASE-SX short wavelength; rugged |
GLC-LX-SM-RGD |
1000BASE-LX/LH long wavelength; rugged |
GLC-ZX-SM-RGD |
1000BASE-ZX extended distance; rugged |
