1325 Heavy Duty Granite , Marble , Stone CNC Caving Router Machine Price
Features of 1325 router cnc for marble and granite:
This 1325S is our professional stone 3d engraving cnc router.
1. Its structure is welded with thick square pipe, which strenthen hole lathe bed stability.
2. X and Y axis is transmissed by helical rack and Z axis is ball screw tranmission with high precise.
3. We adopts Leadshine stepper driving system with high-speed, high precision and long service time.
4. Our machine is controlled by NC-studio with computer, which shows whole manufacturing process on screen.
5. Optional parts: Air-cooling spindle, DSP handle control system, servo motor and driver, etc.
Application of 1325 router cnc for marble and granite:
It is widely used for marble, granite, tombstone, ceramic tile etc material for relief carving and plane engraving. It also can engraving and cutting wood, acrylic, aluminum, cooper and brass well.
Parameter of 1325 router cnc for marble and granite:
Description |
Parameter |
X,Y,Z Working Area |
1300x2500x250mm |
X,Y,Z Repositioning Accuracy |
±0.05mm |
Table Surface |
T-slot Table |
Frame |
Welded structure |
X, Y axis transmission |
Rack and Pinion gear |
Z transmission |
Ball Screw |
Rail Configuration |
20 square rail |
Max. Traveling Rate |
25000mm/min |
Max. Working Speed |
15000mm/min |
Spindle Power |
Water cooling 5.5KW(Opitioinal 3.0/4.5/7.5kw) spindle |
Spindle Speed |
24000RPM |
Drive Motors |
Stepper System (Opitional Yaskawa/ Panasonic Servo motors) |
Working Voltage |
AC380V/50Hz/3PH |
Command Language |
G Code |
Operating System |
Ncstudio System (Opitional:DSP) |
Computer Interface |
USB |
Software Compatibility |
Type3,Wentai,Artcut (Option: ) |
Packing Size |
Wooden case |
N.W. |
1600Kg |
|
Wooden Box With Accessories inside
|
1),Electric Box(1pc) or computer control cabinet
|
|
|
(1)Tool box(1 set):
|
a NCStudio Control card(1pc); b Data cable(1pc); c Disc(1pc); d Power cable(1pc); e Knife Tool(1set); f Upper blade wrench(1 set); g T-clip(1 set); h Allen wrench(1 set); I toolholder; j Random Software Data sheet(1pc); k Pump(2pcs); l packing list(1pc)
|
|
For offer the most suitable machine with favorable price, would you like to confirm below questions:
======================================
1) What is your reuqested max working area, X:___mm, Y:___mm?
2) What mainly job you do ? Only engrave, cut or both ?
3) What kind are your materials, metal or non-metal, what are they?
======================================
After your return comments, we will send you more information about the machine along price . Thanks.
