1.3 MegaPixel 960P HD Network 60m IR Bullet Camera With 9-22mm Lens
- Xiamen
- Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | COOP | |
| Model Number | HD13IRBK | Type | Digital Camera | |
| Style | Bullet Camera | Sensor | CMOS | |
| Technology | NetWork | Special Features | Waterproof / Weatherproof |
Product Description
Model NO.:HD13IRBK
.Core chipset:TI DM365+Aptina 0130,Resolution optional: 1280*960P,720P and D1
.Minimum Illumination:Color:0.4 lux@ F1.7,B/W:0.01lux @ F1.7,
.Support ONVIF 2.0 standard version or GB2818 protocol,
.Support Dual stream (H.264),Stream:1M-8Mpbs adjustable,
.Support multiple screen display software and back-end centralized management .Support more open protocols:TCP,UDP,HTTP,FTP,DHCP,DNS,POP3 and RTSP etc,
.Support 1ch local analog output, 2.8-12mm Megapixel VF lens,DC12V,
.Steady current and ir board, 60M IR(9pcs laser leds),
.Special smart IR technology to effectively avoid IR over-exposure, DWS Structure for avoid ir reflection,
.3 Transformers bracket with cables hidden, IP 67, alluminum alloy smart & stylish case, wear-resisting and good heat emission
Technique Diagram
F | Model | HD13IRBK | |||
Basic Function | Feature | Low illumination | |||
CMOS Type | Aptina Imaging CMOS | ||||
CMOS Model | 1/3″1.3Mega HD | ||||
HD Output Image Adjustable | 960P:1280×960P 720P:1280×720P D1:640×480 | ||||
Illumination | Color 0.1Lux/B/W 0.01Lux(F1.2,AGC ON) | ||||
IR Distance | Standard 9pcs Laser Led ,60M IR Distance | ||||
Shutter Speed | IR-CUT | ||||
Lens | 1/60Sec~ 1/100,000Sec,Shutter Speed Adjustable | ||||
Exposure Control | Std:9-22mm(F1.2 /M12Mount)Mega HD Lens | ||||
AGC & W/B | DSP Auto Adjust | ||||
S/N Ratio | Auto | ||||
Feature | ≥50dB | ||||
Network Function | Network Steadiness | Auto Reconnect, Register, UPNP, HB Display, Synchronization | |||
Support Agreement | Support Onvif2.0, PPPOE,DHCP,TCP/IP,HTTP,UDP,RTP/RTCP,RTSP,UPNP,SMTP,FTP,NTP,DDNS,DNS etc. | ||||
Dual Stream | Dual Stream Transfer(H.264,CBR/VBR Adjustable. Main Stream(1M~8Mbps)With Local Skim, SD Card etc. Sub-Stream(0.5MK~2Mbps)With Network Transfer, 3G Visit. | ||||
Upgrade maintenance | Support Remote Upgrade, With Password Protect. | ||||
Wireless | Adapting WIFI or 3G,Adapting P2P Intelligence Mobile Phone Visit | ||||
Special Features | Optional Function | Paid Option:POE | |||
3-Axix | With portable & fast 3-Construction for Adjust. | ||||
Adjustable Window | On the Down Side of Unit for Adjust Menu | ||||
Vandal Proof Housing | Metal Vandal Proof Body, Dual Ring Transparent Glass | ||||
Waterproof | Strong Waterproof Stopper for IP67 | ||||
Smart IR | Intelligence Prevent IR light Over Exposure | ||||
Smart Alarm | Motion detect,Video Shelter,I/O Alarm for Video Lost, IP Address Conflict, Store Abnormal. | ||||
Video Efficiency | Video Frame Rate | 1280×720P | |||
Effective Pixel | 50Hz/60Hz: 30fps,25fps | ||||
Image Capture | JPEG for local storage | ||||
Image Setting | Saturation, Luminance, Contrast Ratio Adjustable Through Client or IE. | ||||
Image rolling-over | Level Transposition, Turn Up-Side Down, Easy for Install & Adjust. | ||||
Audio | Audio Function | With G.726/G.722/G.711 Standard Code,64Kbps Transfer Speed | |||
Audio Output frame | Audio Cast, Tack Back | ||||
Mount | Power supply mount | DC Female Mount,5.5×2.1mm | |||
Network Mount | 1 ch10M/100M for Ethernet,RJ45 Mount | ||||
Video Output | 1ch Local Analog Output,BNC Mount | ||||
Alarm Mount | 1ch Alarm Input,1ch Alarm Output | ||||
Audio Mount | 1ch Audio Input,1ch Audio Output | ||||
RS485 Mount | 1ch RS485 Mount | ||||
Others | Work Temperature | Circle Temperature:-10°C~+60°C Body Temperature:25°C~35°C Work Humidity:<90% (No Condensation) | |||
Power Consumption | DC 12V±5% ,IR ON: 8W | ||||
Size (mm) | Unit Pack:380 × 155 × 110 mm Carton Size:610×430×400 mm(10 CTN) | ||||
Weight(Kg) | Unit Weight:1.85 Kg~1.95 Kg Carton Weight:18.50 Kg~19.50 Kg | ||||
