1080P Megapixel Auto IR Night Vision Dummy Camera Indoor ONVIF Analog Type Dome P2P Camera smartphone android HD-SDI Camera
Feature:
Adopt Panasonic 34041+ NVP2421(DSP) 1080P 1920+1080(30FPS)2Mega Pixels;
With Chinese/English OSD control; RS485; Remote control;
With BNC coaxical cable control; multi-color of background optional;
2D/3D DVR, Electric-shutter (Manual /Auto); IR-CUT;
Color:0.5Lux F1.2, B/W: 0.05Lux F1.2; Video output: HD- SDI BNC;
DWS avoiding IR diffusion, Hiddem cable bracket; IP66 waterproof;
Infrared focus correction-asphercial zoom lens; focusing accurate, clear image;
IR light strength adjusted; with analog Video Test port;
Std:4-9mm ; IR distance:35M; Power Supply: DC12V
4 structure metal vandal-proof IR dome camera, Ceiling and inbedding installing optional
Support D-WDR, 2D-DNR, IR-CUT FILTER
General | |
Model |
HD-20VDVI-SDI |
Camera Type |
HD-SDI Camera |
CMOS Type |
Adopt Panasonic 34041+NVP2421(DSP) |
Lens |
4-9mm 2Mega Pixels |
IR Distance |
35M |
Image Resolution |
1080P 1920+1080(30FPS) |
Power Supply |
Power adapter: 12V(min 0.5A) |
Image Resolution |
1080P(1920×1080)30Hz/25Hz |
Sensor Specifications |
1/2.5 inch |
Pixel Size |
2.2um x 2.2um |
Color System |
Ycbcr 16bit |
Video Output |
HD-SDI (SMPTE274M standard) |
Video Output Interface |
BNC |
Shooting Speed |
30fps/25fps |
Min. illumination |
0.1LUX (single-frame and color mode) |
OSD |
Support multiple languages (up to 30 and flexible customize) |
Scene Mode |
General/Highlight |
Infrared Switch |
Auto/Color/Gray |
HDR |
On/Off |
Analog Gain |
On/Off |
2D DNR |
On/Off |
Automatic Exposure Response Speed |
8 frames |
AWB |
Auto/Mode 1/Mode 2/Mode 3/Off |
CCM |
On/Off |
DPC |
On/Off |
Brightness/Contrast/ |
0~255 adjustable |
Self Adaption |
On/Off |
Auto Iris |
Selectable |
Transmission Distance (Non-Relay) |
Min 300m (the quality of coaxial cable is optional) |
Power Consumption |
Max 2W (with 12V power supply, IR off) |
Wateproof |
IP66 |
Working Environment |
Temperature: - 10°C ~ + 50°C Humidity: ≤ 90% |
HD-SDI 1080P CCTV Camera Series
COOPSECURITY is professional security equipment supplier committe to provide secuiry surveillance goods.
There are wide range of security camera to cover everything. From home design camera with night vision and outdoor project bullet ip ptz and HD resolution camera. Also the related accessoires. All of product were technological updated contantly.
We are hoping to offer you the eco device that low power comsuption, good reliability long life and secure enviroment.
Fair
Certification if you need CE ROHS
