4ch 2mp 1080p Surveillance Home Cctv Security Camera System

Name: 4ch 2mp 1080p Surveillance Home Cctv Security Camera System
Brand: COOP
SKU: 103879409
Availability: InStock

US$ 200 - 300 MOQ: 1 Set

Key Specifications

Place of Origin:

China

Brand Name:

COOP

Model Number:

HP6508H

Coop Security Technology(Quanzhou)Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name COOP

Model Number HP6508H

4ch 2mp 1080p surveillance home cctv security camera system

1. Support 1channel BNC output, 1channel. VGA output

2. Support Email alarm . Mobile phone surveillance (Win CE/Symbian/iPhone/Blackberry)

3. Support PTZ Control

4. Support Multi-language OSD

5. Supports mouse, remote controller operating

Product Specifications

Model No.	HP6508H
Main Function
Operating system	Embedding Linux OS
Video Compression Format	Main Profile H.264
Video Input	8Channels BNC
Video Output	1 Channel BNC, 1 Channel VGA
Audio Input/Output	8 CH RCA/1CH RCA
Display Picture	1/4/8CH PIP/ZOOM
Multiplex Operation	LivedisplayPlaybackRecordingBackup Mobile phone Surveillance Network simultaneously
Display Resolution	PAL:D1(704576),NTSC:D1(704480)
Recording Mode	ManualTimerMotion DetectionRemote
Recording Frame Rate	PAL:D1@100fps,HD1@100fps,CIF@100fps NTSC:D1@120fps,HD1@120fps,CIF@120fps
Recording Resolution	PAL:D1(704576),HD1(704288),CIF(352288) NTSC:D1(704480),HD1(704240),CIF(352240)
Recording Playback	1/4/8CH Playback
Alarm in/Out	8CH/1CH (Optional)
Recording Backup	USB,Moved Hard Disk.Network
Recording Play	Special player
Email Alarm	Send pieces to the designated email
PTZ protocol	PELCO-D,PELCO-P
HDD	Support 1 SATA HDD, capacity to 2TB
HDD Remain Time Hint	Support
Network and Protocol	RJ-45 10/100M via Ethernet, Support TCP/IP,PPPOE,DHCP,DDNS
IE Browser	Windows XP/Vista/Win 7/Mac OS,IE6.0-9.0/Firefox/Chrome/Opera/Apple Safari
Client Software/CMS	Support(One software for at most 200 DVRs),Mac O.s
Dual Stream	Support(Main and secondary interchange)
Multi-language	Support
Mobile Phone Surveillance	Support Windows Symbian iPhoneBlackberry Operation System
Mouse Interface	USB2.0
Backup interface	USB2.0
Remoter Controller	Support
Power	DC12V/3A
Working Temperature	-10°C-60°C
Working Humidity	10%-90%
Size	35423045mm(LDH)
