US$ 5 - 30
MOQ: 10 Pieces
Key Specifications
Get Latest Price
LED Light Source:
COB led
Warranty(Years):
2
Input Voltage(V):
85-265
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Newest Best Quality 3w - 15w Warm White 4000-4500K COB Led DownlightUS$ 7.37 - 30.66MOQ: 2 Pieces -
Led Downlight Bulb 15w 1250lm CRI>75 2 Years Warranty 9-12w Led Ceiling Downlight, Led DownlightUS$ 7.37 - 30.66MOQ: 2 Pieces
-
ALUMINUM RECESSED 3W - 15W COB LED DOWNLIGHTUS$ 7.37 - 30.66MOQ: 2 Pieces
-
Shenzhen Factory Best Price for High Quality 3W 5W 10W 12W 15W Dimmable Led Downlight With CE ROHSUS$ 7.37 - 30.66MOQ: 2 Pieces
-
Newly Designed Sharp Dimmable LED Downlight With 188mm Cutout 12w Led Downlight With 2 Years WarrantyUS$ 7.37 - 30.66MOQ: 2 Pieces
LED Light Source
COB led
Warranty(Years)
2
Input Voltage(V)
85-265
Lamp Power(W)
10
Lamp Luminous Flux(lm)
650
Lamp Luminous Efficiency(lm/w)
80
Color Temperature(CCT)
Pure White
Working Temperature(℃)
-30, 50
Working Lifetime(Hour)
50000
Lamp Body Material
Aluminum
IP Rating
IP44
Certification
CCC, CE, FCC
Model Number
GL-4TD-10
Place of Origin
Guangdong, China
Brand Name
gielight
Specifications
cob down light1.led type COB
2.CE ROHS
3, 2 years warranty
4, AL+ Toughened glass
3inch COB led downlight
led downlight parameters
| Type No. | Watt | LED Type | Input | Lumen | Actual Size | Cutting |
| GL-2.5TD-3 | 3W | COB | 100-240Vac | 200lm | 98*71mm | 90mm |
| GL-3TD-5 | 5W | COB | 100-240Vac | 320lm | 108*74mm | 100mm |
| GL-4TD-10 | 10W | COB | 100-240Vac | 650lm | 141*88mm | 120mm |
Electrical Parameters:
LED Panel Output Voltage: 26Vdc
External Driver Input Voltage: 100-240Vac
Frequency: 50/60Hz
Optical Parameters:
Light Efficiency: 75-85LM/W
Color Temperature: Pure white, Warm white
Other Parameters:
Product Patents: Yes
Operating Temperature: -20°C-50°C
Storage Temperature: 0-35°C
Main Material: Aluminum
IP Rating: IP40
Life Span: 50,000hours
Warranty:2 years
Within the warranty period,Gielight bears the shipping cost back and forth of replacing defective goods.
For more informations.pls contact me freely!
