1/3'' Sony HDIS 960P With IR-Cut IP67 Waterproof Infrared technology AHD Camera

Name: 1/3'' Sony HDIS 960P With IR-Cut IP67 Waterproof Infrared technology AHD Camera
Brand: COOP
Price: Negotiable

FOB Price

Negotiable / Piece

5 Pieces(Min.Order)

Product Details

1.3Mega 1/3'' HDIS 960P With IR-CUT IP67 Waterproof IR Bullet camera

Model NO.:AHD-960P-P

Feature:

1.3M 960P AHD output

CVBS output 16:9 image, 800TVL.

SONY 1.3Mega Exmor IMX238LQJ sensor

The latest AHD high speed processor

40M IR Distance,42pcs Black IR Leds

Super low illumination 0.0008LUX

Multi protection design: over-voltage protection/ static protection/lightning proof protection

Smart LED Infrared avoid over-exposure

3 bracket

Adopt Japan power IC Design, wide voltage, working voltage min. +5V, max.24V.

OSD Menu.

5-second-Press Menu left button and right button to switch CVBS and AHD output signal.

Technical Specification

Model Number	AHD-960P-P
SENSOR	SONY 1/3” Exmor CMOS IMX238
Size	32mm32mm/38mm38mm
Chipset	NVP2430H+238
Output Resolution	AHD 960P /CVBS 1300 TVL
Signal Sys.	PAL/NTSC
Total Pixel	1312(H)×1069(V) 1.4M Pixels
Valid Pixel	1280(H)×1024(V) 1.31M Pixels
Min Illumination	Color 0.02Lux(F1.2,50IRE,AGC ON); B/W: 0.0008Lux(F1.2,50IRE,AGC ON)
Electric Shutter	PAL :1/50 ~ 1/100,000s NTSC:1/60 ~ 1/100,000s
WDR	D-WDR
Sens-up	0-30X
2D-DNR	off/ low/ medium/ high
3D-DNR	off/ low/ medium/ high
Image-frozen	Support
BLC/HLC	Support
Defogger	0-2 Level
S/N	> 60dB
White Balance	Auto White balance
Day/Night	Auto/ manual / Color/ B/W
Mirror	Horizontal/ Vertical
Privacy Mask	Support
OSD Language	Chinese/ English/ German/ French/ Italian/ Spanish/ Portuguese/ Russian/ Dutch/ Turkish/ Polish
Video Output	1.0Vp-p compound output, 75Ω
Power	DC 12V±50%
Working Temperature	-20℃~60℃
Working Humidity	Relative humidity less than 90%
