Microscope NTX Series

Name: Microscope NTX Series
Brand: Novel
SKU: 103837455
Availability: InStock

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Novel

Model Number:

NTX series

Nanjing Jiangnan Novel Optics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Novel

Model Number NTX series

Theory Stereo Microscope

Drawtube Binocular

			NTX-1A	NTX-1B	NTX-1C
Head	Straight Binocular Viewing Head		S	S	S
Eyepiece	WF5×		O	O	O
	WF10×		S	S	S
	WF15×		O	O	O
	WF20×		O	O	O
Objective	Inserted Objective	1×	O	O	O
		2×	S	S	S
		3×	O	O	O
		4×	O	O	O
		6×	O	O	O
Working Distance	80mm		S	S	S
Illumination	No Light		S
	Epi-illumination 12V/10W			S	S
	Diascopic Illumination 12V/10W				S

			NTX-2A	NTX-2B	NTX-2C	NTX-3A	NTX-3B	NTX-3C
Head	Inclined Binocular Viewing Head, Unrotatable		S	S	S	S	S	S
Eyepiece	WF5×		O	O	O	O	O	O
	WF10×		S	S	S	S	S	S
	WF15×		O	O	O	O	O	O
	WF20×		O	O	O	O	O	O
Objective	Inserted Objective	1×	O	O	O
		2×	S	S	S
		3×	O	O	O
		4×	O	O	O
		6×	O	O	O
	Objective	2×,4×				S	S	S
		1×,2×				O	O	O
		1×,3×				O	O	O
Working Distance	80mm		S	S	S
Working Distance	57mm					S	S	S
Illumination	No Light		S			S
	Transmitted light 6V/12W			S	S		S	S
	Incident light 6V/12W				S			S

			NTX-5A	NTX-5B	NTX-5C	NTX-6C-W
Head	Inclined Binocular Head, 360° Rotatable		S	S	S	S
Eyepiece	WF5×		O	O	O	O
	WF10×		S	S	S	S
	WF15×		O	O	O	O
	WF20×		O	O	O	O
Objective	Inserted Objective	2×,4×	S	S	S	S
		1×,2×	O	O	O	O
		1×,3×	O	O	O	O
Working Distance	76mm		S	S	S	S
Illumination	No Light		S
	Epi-illumination 12V/10W			S	S	S
	Diascopic Illumination 12V/10W				S	S
