Help CenterHDPE/LDPE/LLDPE Film Blowing Machine Screw and Barrel
Related Products
Specifications
The screw an barrels are made of special nitro alloy steel nitrided with mirror finish. The barrel is honed or with spiral groovProducts:
1.Conical(parallel) twin screw& barrel
Production scope:
Conical twin screw and double holes cylinder Φ35/70~Φ92/178
Parallel twin screw and double holes cylinderΦ35/35~Φ250/250
CINCINNATI, BATTENFELD, KRUSSMAFFEI, BAUSANO and AMUT model spares.
2.Screw & barrel for single screw extruder
Production scope: Screw diameter Φ20~Φ500
Maximum screw length 10,000mm
Barrel inner bore diameter Φ500mm
3.Screw & barrel for injection molding machine
Production scope: Screw diameter Φ20~Φ500
Maximum screw length 10,000mm
Barrel inner bore diameter Φ500mm
4.Assembly parts of screw & barrel
Technical data:
Depth of Nitrated Layer: 0.5-0.8mm Hardness of nitration: 900-1020Hv
Fragility of nitration: Less than grade 1 Surface roughness: Ra 0.4um
Hardness of Cr-coating Layer: ≥950Hv Thickness of Cr-coated Layer: 0.03-0.08m
Hardness of Bimetallic Layer: HRC55-72 Depth of Bimetallic Layer: >2mm
