Home > Products > Guide System > Elevator Parts/Elevator Cold Drawn Guide Rail T45/A, T50/A
Elevator Parts/Elevator Cold Drawn Guide Rail T45/A, T50/A
- 100000 Ton / Tons per Month
- Zhangjiagang port
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | Banda | Model Number: | T45/A T50/A T70-1/B |
Product Description
Elevator Cold Drawn Guide Rail
1.Specifications:T45/A T50/A T70-1/B
2.All rails Meet ISO 7465 standard
3.Material: SS400
Cold Drawn Elevator Guide Rail, Elevator Rail,Elevator Cold Drawn Guide Rail,T45/A T50/A T70-1/B Elevator Cold Drawn Guide Rail,T45/A T50/A T70-1/B Cold Drawn Rail
Banda has been supplying and exporting various types of elevator cold drawn guide rails in big volume every year as follows:
1.Specifications: T45/A T50/A T70-1/B
2.All rails meet ISO 7465 standard.
3.Fishplate, rail clip, bolts and nuts available
4.Standard export package: T45/A and T50/A:40pcs/bundle, T70-1/B:20pcs/bunndle
5.Dimensions of Clod Drawn Guide Rail
Elevator Cold Drawn Guide Rail Drawing:
Elevator Cold Drawn Guide Rail Specifications:
| Type | b1 | h1 | k | n | P | RS | m1 | m2 | t1 | t2 | d | b3 | l2 | l3 |
| Tolerance | ±0.5 | ±0.2 | ±0.15 | ±0.5 | +0.06/-0 | +0/-0.06 | ±0.1 | ±0.1 | ±0.2 | ±0.2 | ±0.2 | |||
| T45/A | 45 | 45 | 5 | 5 | 1 | 9 | 25 | 65 | 15 | |||||
| T50/A | 50 | 50 | 5 | 5 | 1 | 9 | 30 | 75 | 25 | |||||
| Tolerance | ±1.5 | ±0.1 | +0.1/-0 | +3/-0 | ±0.75 | +0.06/-0 | +0/-0.06 | ±0.1 | ±0.1 | ±0.2 | ±0.2 | ±0.2 | ||
| T70-1/B | 70 | 65 | 9 | 34 | 7 | 1.5 | 3 | 2.95 | 3.5 | 3 | 13 | 42 | 105 | 25 |
Elevator Guide Rail Packing:
