Good Quality Cenosphere/hollow Microsphere for Thermal Insulation Manufacture
- Shanghai/Qingdao
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
-
Microsphere Cenosphere/cenosphere/ 150mesh All Pass Cenospheres
-
Microsphere Cenosphere for Chemical/coating/print
-
High Grade Hollow Microsphere, Glass Floater, Cenospheres
-
Selling Refractory Application Powder Shape Cenosphere 20 Mesh
-
Corundum Thermocouple Protection Tube
-
High Purity AL2O3 Ceramic Tube Alumina Corundum Tube 99%
Product Details
| Place of Origin | Henan, China | Shape | Ball | |
| Material | MgO-Carbon Brick | SiO2 Content (%) | 55-60% | |
| Al2O3 Content (%) | 30-35% | MgO Content (%) | 0.8-1.2% | |
| CaO Content (%) | 1.2-1.7% | |||
| CrO Content (%) | N/A | SiC Content (%) | N/A | |
| Model Number | JK-microsphere-002 | Brand Name | JK |
Product Description
Good quality Cenosphere/hollow microsphere for thermal insulation manufacture
Introduction:
Cenosphere, sometimes called microsphere, is a light weight, inert, hollow sphere made largely ofsilica and alumina andfilled with air or inert gas., typically produced as a byproduct of coalcombustion at thermal power plants. The color varies from gray to almost white and their density is about 0.6-0.9g/cm³, all these property give it a widely application for insulation,refractory,oil drilling,coating,construction use.
Cenosphere Features:
1) Excellent fluidity
In hollow microspherical shape and with size from 20 to 500micron,cenospheres can improve Fluidity of filler and make it easier to be used .
2) Heat-insulating and sound-insulating
Lower conductivity makes it widely used in producing heat-insulation and soundinsulation materials and Equipments.
3) Chemical stability
Chemical features (alumina silicate) of cenospheres can maintain their integrity while they are utilized in Water,organic chemicals acid,alkali and other solvents.
4) High refractoriness
Cenospheres have a high refractoriness. It can still keep a good stability while being heated over 1000C.
5) High Strength
Cenospheres are three to ten times stronger than most manmade hollow glass spheres.Unlike glass spheres,Cenospheres can produce a higher compressive strength due to a stronger outer shell.
6) Lower cost
Cenospheres have an advantage in cost compared with other fillers and man-aade micro spheres.
Cenosphere Specification:
Specs/Grade | Grade1 | Grade2 | Grade3 | Grade4 | Grade5 |
True Density(g/cc) | 0.6-0.7 | 0.7-0.85 | 0.85MAX | 0.8-0.9 | 0.9-1.0 |
Bulk Density(g/cc) | 0.37-0.40 | 0.38-0.41 | 0.39-0.42 | 0.40-0.43 | 0.45-0.5 |
Compress Strength(Mpa) | 20-40 | 40-60 | 40-80 | 40-80 | 50-100 |
Size(micron) | 40-300 | 40-300 | 40-300 | 40-300 | 40-300 |
Float Ratio | 95%min | 95%min | 95%min | 95%min | 95%min |
PH | 7-8 | 7-8 | 7-8 | 7-8 | 7-8 |
Thermal Conductivity(w/m.k) | 0.036-0.060 | 0.036-0.060 | 0.036-0.060 | 0.036-0.060 | 0.036-0.060 |
Refractoriness | 1100-1660C | 1100-1660C | 1100-1660C | 1100-1660C | 1100-1660C |
Color | Grey/White | Grey/White | Grey/White | Grey/White | Grey/White |
Moisture | 2%MAX | 2%MAX | 2%MAX | 2%MAX | 2%MAX |
Kraft Packing | 20KG | 20KG | 20KG | 25KG | 25KG |
Packing-2 | 400KG | 400KG | 450KG | 500KG | 500KG |
The physical propertie:
Composition |
SiO2
|
Al2O3
|
Fe2O3
|
SO3
|
Ca O
|
Mg O
|
K2O
| Na2O
|
Content % |
56-62
|
33-38
| 2-4 | 0.1-0.2 | 0.2-0.4 |
0.8-1.2
| 0.5-1.1 | 0.3-0.9 |
Application of Cenosphere:
1. Paints and ink: ink, bond, vehicle putty, insulating, antiseptic, fireproof paints.
2. Plastics: the products of POM ,PA,PBT,PET,PP and so on. Like panels, boards, vehicle decorations, glass fiber products.
3. Rubber: floors,boards ,wires and lines ,insulating devices, sole, conveyer belt, vehicle parts and bodies, fender-guard, etc.
4. Construction materials: fire and water-proof materials, processed asphaltum, high-level road pavement, concrete repair materials.
5. Encapsulation material: transformer filling material ,electric encapsulation material, electric encapsulation materials.
6. Glass steel products: glass steel furniture, boats, etc.
7.Space or military products: explosives, invisible paints for planes, ships and even soldiers, heat and compression insulating compounds, deep-water submarine.700/mt.
ü 24 hours online after-sale service,enquiry will be replied in time;
ü Experienced Sales answer all your questions refer to the minerals;
ü Samples could be arranged for your evaluation,factory visitied are welcomed;
ü Manufacturing and Loading Pictures could be offered for your refer;
ü Any further needs,pls feel free to contact us,we will do our best to help you.
1. How to order ?
2. Can we accept OEM ?
YES! We can according your demand to produce.
3. Can we accept the detective of the third-party verification company ?
YES! We can accept the detective from any third-party verification company including the SGS, BV and so on.
4.How about the delivery?
The company provides just-in-time delivery with its streamlined supply chain.
5.Why we attend customers queries promptly?
We believe that if customers are satisfied then it proves our worth well.Customers are always given quick support.
