8Ways DMX512 splitter 8CH DMX distributor stage lighting dmx512 signal amplifier

8Ways DMX512 Splitter / Distributor 8CH

DMX Splitter is a DMX512 distribution amplifier It is specially designed for connection of DMX receivers(dimmers,color changers,moving lights,etc.)in a star configuration.
DMX Splitter can surmount the restriction that single RS-485 can only connect 32 sets of equipment.

The multiple output optically isolated DMX512 distribution amplifiers have become necessary in many DMX512 systems.
DMX Splitter provide total electrical ground isolation between different branches of the star.
This greatly decreases problems with ground loops.
It amplifies and refits the DMX signal, that it makes the DMX data transmission more reliable.

 1.Fully compliant to DMX-512 (1990) speciflcation.

 2.Inputs and outputs are true RS-485 rated.

 3.3 pin XLR input and a passive loop through.

 4.8 way isolated DMX splitter output.

 5.Input isolated from outputs over 1000VDC.

 6.Outputs are isolated from each other over 1000VDC.

 7.Power supply, 90~240VAC 50Hz / 60Hz , 15W .

 8.1U high 19 inch rack mount construction.
