Home > Electrical & Electronics > Inverter > Power Inverter > [HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger

[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger

Shenzhen Santek Power Co., Limited
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger thumbnail-1
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger thumbnail-2
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger thumbnail-3
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger thumbnail-4
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger thumbnail-5
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger thumbnail-6
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger photo-1
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger photo-2
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger photo-3
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger photo-4
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger photo-5
[HKSANTEK] Grid Hybrid Solar Inverter 3000W 12V 24V Power Inverter With Built in MPPT Controller and AC Charger photo-6
US$ 320 - 360 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HKSANTEK
Model Number:
SCI
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HKSANTEK
Model Number SCI
Output Power Other, 500W-3000W
Output Type Single
Size 486*400*182mm
Weight 28KG
Input Voltage 220v/110v
Output Voltage 220v/110v
Type DC/AC Inverters
Output Frequency 50/60HZ
Output Current 13AMP

[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger





Product Description



Product Features:

1,pure sine wave inverter with AC charger

2,build in MPPT solar charge controller 40A or 50A

3,working modes switche automatically (AC grid bypass mode ,inverter mode ,AC charging mode ,solar charging mode )

4.Auto transfer between grid power and solar power





Technical Parameters



Product Specification:





ModelSCI500SCI1000SCI1500SCI2000SCI3000SCI4000SCI5000SCI6000
AC INPUT
Waveform & PhasePure sine wave(utility or generator)&Single Phase
Norminal Voltage110/120/220/230/240VAC220/230/240VAC
Voltage Range95-127vac/194-253vac194-253vac
Frequency50HZ or 60HZ(Auto Adjust)
Frequency Range48-54HZ/58-64HZ
AC OUTPUT
Waveform & PhasePure sine wave(utility or generator)&Single Phase
Norminal Voltage110/120/220/230/240VAC220/230/240VAC
Frequency50HZ or 60HZ(Auto detect)
Peak Power3 times of ratings
BATTERY
Battery DC12V/24V12V/24V/48V24V/48V
DC Input10-16V/20-32V/40-64V
Over Charging15.7V/31.4V/62.8V
Max Charing Current20A-75A
Battery TypeGEL,AGM,Sealed lead acid
MPPT CONTROLLER
PV Input15-30VDC/30-55VDC
Max Charing Current20A/30A/40A/50A
Max.Output Current15A
TRANSFER EFFICIENCY
MPPT Efficiency>95%
Line Mode>95%
Battery Mode>85%
Power SaverAvailable When The Load Is Less Than 50Watts
Transfer Time10ms
INDICATORS
7-LED DisplayFrom Right To Left:1.Line Mode(Green),2.Inverter Mode(Green),3.Charging Mode(Yellow),4.Fully Charged(Green),5.Over Temp(Red),6.Overload(Red),7.Saving Mode(Green)
2-LED Display(MPPT)Power,CHG.Mode
3-LED DisplayCharging Mode(Greening Lighting),Inverter Mode(Greening Lighting),Alarm(Red Lighting)
LCD DisplayInput Voltage,Output Voltage,Frequency,Battery Voltage,Load
Switch SelectorSaving Mode Is On/Off When Push The Switch Forwards/Backwards,Keeping It Horisontal Is Turning The Inverter Off
Working ModeAC Power Priority(1-6)/Battery Power Priority(7-9)
ProtectionsOver Temp,Over Load,Over Voltage,Shortdown
CommunicationsRJ11/RS232(Optional)
ENVIROMENTAL
Operating Enviroment0-40°C,0-95%Rh(non-condesing)
Audible Noise<60dB
Dimension D×W×H(mm)486*400*181486*432*181
Net Weight(KG)1820.822.824.529.1404850









Product Pictures



Product Show:


[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger



[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger





How It Work



[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger



Packaging & Shipping

 [HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger



Delivery Time:

Sample Lead time:5 days
Production lead time:20days  (subject to the actual quantity)


[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger







About us





[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger





[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger

[HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger





 [HKSANTEK] Grid hybrid solar inverter 3000W 12V 24V power inverter with built in MPPT controller and AC charger
