Home > Products > 36V solar module > High Quality 170W-200W Solar Modules
High Quality 170W-200W Solar Modules
- shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | STS | |
| Model Number | STS-5M-(170-200)M-72 | Material | Monocrystalline Silicon | |
| Size | 1580*808*40 | Number of Cells | 72 | |
| Max. Power | 170w-200w |
Product Description
High quality 170W-200W solar modules
Efficiency
1. Low voltage-temperature coefficient allows higher power output at high-temperature condition.
2. High efficient, high reliable solar cells ensure our product output stability.
Benefits
1. Manufactured in an ISO9001:2008 certified plant
2. High efficiency, high safety, high reliability
3. Output power tolerance of +/-3%
Warranty
1. 10-years limited warranty on materials and workmanship
2. 25-years limited warranty on power output: 10 years/90%, 25 years/80%
Specifications
Model Type | STS-5M-180M-72 | STS-5M-185M- 72 | STS-5M-190M-72 | STS-5M-195M-72 | STS-5M-200M-72 |
Peak power | 180W | 185W | 190W | 195W | 200W |
Cell type | Mono Crystalline Silicon,125×125mm | Mono Crystalline Silicon,125×125mm
| Mono Crystalline Silicon,125×125mm | Mono Crystalline Silicon,125×125mm
| Mono Crystalline Silicon,125×125mm |
Number of cells | 72 cells in series | 72 cells in series
| 72 cells in series
| 72 cells in series
| 72 cells in series
|
Weight | 15.5kg | 15.5kg | 15.5kg | 15.5kg | 15.5kg |
Dimensions | 1580*808*40mm | 1580*808*40mm | 1580*808*40mm | 1580*808*40mm | 1580*808*40mm |
Maximum power voltage(Vmp) | 36.42V | 36.54V | 36.66V | 36.96V | 37.26V |
Maximum power current(Imp) | 4.94A | 5.06 | 5.18 | 5.28 | 5.37 |
Open circuit voltage(Voc) | 44.88V | 45.18V | 45.38V | 45.50V | 45.62V |
Short circuit current(Isc) | 5.44A | 5.52A | 5.58A | 5.63A | 5.66A |
Maximum system voltage | DC 1000V | DC 1000V | DC 1000V | DC 1000V | DC 1000V |
Temp.Coeff.of Isc(TK Isc) | +0.036%/°C | +0.036%/°C | +0.036%/°C | +0.036%/°C | +0.036%/°C |
Temp.Coeff.of Voc(TK Voc) | -0.33%/°C | -0.33%/°C | -0.33%/°C | -0.33%/°C | -0.33%/°C |
Temp.Coeff.of Pmax(TK Pmax) | -0.47%/°C | -0.47%/°C | -0.47%/°C | -0.47%/°C | -0.47%/°C |
Normal Operating Cell Temperature | 45±2°c | 45±2°c | 45±2°c | 45±2°c | 45±2°c |
-0.33%/°C
-0.33%/°C
Carton box, loaded on pallet or wooden case
