7.2V 6.5Ah Hybrid car battery pack for Honda Civic and Insight
Application scope:Honda Civic 2003-2005,Insight 1999-2006, Toyota prius NHW10
Quantity:20 sticks
Type:NI-MH
- Size:D
- Nominal Voltage:7.2V
- Nominal Capacity:6500mAh
- Warranty: 4 year
- Place of Origin:China (Mainland)
6 Cell per stack with both ends stainless square and hexagonal standard electric car battery Nuts and inter-connecting cups, rubber heat sealing sleeves and all necessary accessories.
1.2V single cell specification:
Item |
Specification |
|
|
Dimensions |
Outer Diameter (mm) |
32.2±0.07 |
Over Height (mm) |
60.5±0.2 |
|
Approximate Weight(g) |
165 |
|
Nominal Capacity(mAh) |
≥6500(IEC) |
|
Nominal Voltage(V) |
1.2 |
|
Internal Resistance (mΩ) |
≤1.6 |
|
1.2V Discharge Capacity1.2V Cut |
≥70% |
|
Specific Energy (Wh/kg) |
≥45 |
|
Peak Power (W) |
≥130(DOD50%) |
|
Specific Power(W/kg) |
≥850(DOD50%) |
|
(30C Discharge,70%SOC,0.8V Cut-off) |
≥10S |
|
Peak Charging (15C Charge, 50%SOC, 1.66V Cut-off) |
≥10S |
|
Max Discharge (15C Discharge, 70%SOC,0.8V Cut-off) |
≥60S |
|
High Temperature Performance(50°C Charge/Discharge Capacity Rate) |
≥70% |
|
Low Temperature Performance(-20°C Discharge Capacity Rate) |
≥80% |
|
Charge Retention(30 Day) |
≥75% |
|
Working Temperature |
-20°C to +55°C |
|
Storage Temperature |
-40 to +65°C |
|
Cycle Life(C/3 Charge,1C Discharge) |
≥800cycles |
|
7.2V NI-MH Battery Package(7.2V HEV Battery stick)
Item |
Specification |
|
|
Dimensions |
Outer Diameter (mm) |
34.0 |
Over Length (mm) |
396 |
|
Approximate Weight(g) |
1100 |
|
Nominal Capacity(mAh) |
6500(IEC) |
|
Nominal Voltage(V) |
7.2 |
|
Internal Resistance (mΩ) |
≤9.6 |
|
7.2VDischarge Capacity7.2V Cut |
≥70% |
|
Specific Energy (Wh/kg) |
≥45 |
|
Peak Power (W) |
≥130(DOD50%) |
|
Specific Power(W/kg) |
≥850(DOD50%) |
|
Peak Discharge(30C Discharge, 70%SOC, 4.8V Cut-off) |
≥10S |
|
Peak Charge(15C Charge, 50%SOC, 9.96V Cut-off) |
≥10S |
|
Max Continuous Discharge(15C Discharge, 70%SOC, 4.8V Cut-off) |
≥60S |
|
High Temperature Performance(50°C Charge/Discharge Capacity Rate) |
≥70% |
|
Low Temperature Performance(-20°C Discharge Rate) |
≥80% |
|
Charge Retention(30 Days) |
≥75% |
|
Working Temperature |
-20°C to +55°C |
|
Storage Temperature |
-40 to +65°C |
|
Cycle Life(C/3 Charge,1C Discharge) |
≥800cycles |
|
