Product Name: 20 Head automatic mix multihead weigher for food packaging machine or mixing purpose
Model: JW-A20
1. Application
* It is suitable for integrating with high speed packaging machine or mixing purpose.
2. Features
* Arc-shaped machine frame and new machine body cover, improves stability and appearance.
* Integral machine frame with middle standing increases the stability of machine frame and hoppers.
* Stable actuator design makes the new hoppers work better and read weight figure quickly.
3. Mechanical Character
* Second generation modular control system.
* Standard industrial control system.
* Stagger dump function.
* Double discharging chutes to work with twin packaging machine.
* Upper storage funnel is divider to weigh two different materials.
4. Technical Specification
| Model | JW-A20 |
| Identify Code | A20-2-2 |
| Single Weighing Range | 10-1000g |
| Accuracy | X(0.5) |
| Max Speed | 130 P/M |
| Hopper Volume | 1.6/2.5 L |
| Control Panel | 10.4 '' Touch Screen |
| Options | Dimple Plate /Timing Hopper/Printer/Reject Device |
| Driving System | Step Motor |
| Power Requirement | 220V/2000W/50/60HZ/16A |
| Packing Dimension(mm) | 1950(L)X1650(W)X1620(H) |
| Gross Weight | 850kg |
5.Deminsion
