Metallographic Sample Specimen Cutter Machine QG-1
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
SIOMM
Model Number:
QG-1
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Metallographic Sample Specimen Cutting Machine QG-1NegotiableMOQ: 1 Set -
Metallographic Sample Cutting MachineNegotiableMOQ: 1 Set
-
1700C Box Type Vacuum Atmosphere Furnace (SQFL-1700)NegotiableMOQ: 1 Set
-
1100C Box Type Vacuum Atmosphere Furnace (SZFL-1100)NegotiableMOQ: 1 Set
-
1400C Box Type Vacuum Atmosphere Furnace (SQFL-1400)NegotiableMOQ: 1 Set
Brand Name
SIOMM
Model Number
QG-1
Place of Origin
Shanghai, China
Specifications
1.it is generally used for cutting metallographic2..it is equiped with a cooling channel and a switch
metallographic specimen cutter machine QG-1
Product Description:
This machine is generally used for cutting metallographic, petrographic sample material. The machine equipped with a cooling channel and a switch.. And the heat generated during cutting can be take away by cooling liquid, to avoid burning by overheating. It with the features of easy operation, safe and reliable. So it is one of the essential equipment of the laboratory to preparing sample specimen.
Specification:
Maximum cut-off width |
50mm |
Maximum cut-off height |
70mm |
Maximum cut-off cross-section diameter |
Φ50mm |
Abrasive wheel |
250x2.0x32mm |
Motor |
Y80L-1.1kw |
Overall dimensions |
600x620x470mm |
Weight |
75kg |
