Rated power 5KW/5.5KW petrol power generator13HP KC6500 gasoline generator set with electric start

FOB Price

USD $200 - $265 / Set

50 Sets(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Rated power 5KW/5.5KW petrol power generator13HP KC6500 gasoline generator set with electric start

Product Description

Generator	Specification	KC3500		KC4500		KC5500		KC6500
	Rated rotation speed(rpm)	3000	3600	3000	3600	3000	3600	3000	3600
	Rated voltage(V)	115 230 120/240
	Max. output power(W)	3300	3500	3800	4000	4300	4500	5500	5700
	Rated output power(W)	3000	3200	3500	3700	4000	4200	5000	5200
	Rated Frequency(Hz)	50	60	50	60	50	60	50	60
	Phase	Single Phase
	DC output	12V×8.3A
	Voltage regulate	AVR
	Power factor	1.0	1.0	1.0	1.0	1.0	1.0	1.0	1.0
	Continuous running time(hrs)	13	13	11	11	10	10	8	8
Engine	Bore×stroke(mm)	73×58		77×58		82×64		88×64
	Displacement(cm3)	242		270		337		389
	Compression Ratio	8.2:1		8.2:1		8.0:1		8.0:1
	Recommend power Output(HP/rpm)	8/3600		9/3600		11/3600		13/3600
	Max Torque N.m/rpm(N.m/rpm)	17/2500		19/2500		23.5/2500		25.5/2500
	Fuel	Gasoline
	Satrting system	Recoil/Electric
	Lgnition system	TCI	TCI	TCI	TCI	TCI	TCI	TCI	TCI
	Oil capacity(L)	1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1
	Fuel tank capacity(L)	25	25	25	25	25	25	25	25
	Engine type	KC168F-1	KC168F-1	KC177F	KC177F	KC177F	KC177F	KC188	KC188
	Noise level(7m)(Db)	68	68	69	69	72	72	76	76
Parking Details	Measurement(mm)	710×530×550
	N.W./G.W.(Kg)	67.5		70		72		74.5
	Loading quantity in 20'	128		128		128		128
	Loading quantity in 40'	264		264		264		264
	Loading quantity in 40'HQ	264		264		264		264

---Features

1. The start power of generator set is a qualified gasoline engine,insuring fuel burning effectively and economically.-

2.Adopting several reliable measure for shock protection,with a small shocj of the whole sets.

3.with a whole closed structureset,adopting light materials,small cubage and light weight..

4.Circuit breaker to stop engine automatically when overloaded
5.CE, SONCAP, ISO certification approved
6.One year warranty
