Good Tensile Yield Ratio Spring Steel 1.0961 Steel Roll Bar

Name: Good Tensile Yield Ratio Spring Steel 1.0961 Steel Roll Bar
Brand: SongShun
SKU: 103338407

US$ 100 - 2,200 MOQ: 20 Tons

Key Specifications

Steel Grade:

Spring Steel

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Dimensions:

Dia 50-400mm, length 2000-4500mm

Dongguan Songshun Mould Steel Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Steel Grade Spring Steel

Standard AISI, ASTM, BS, DIN, GB, JIS

Dimensions Dia 50-400mm, length 2000-4500mm

Place of Origin Guangdong, China

Brand Name SongShun

Model Number 9254/1.0961/60SiCr7/SUP12/60Si2CrA

Technique Other, hot rolled or forged or cold drawn, Hot work or Forged

Application Other, Extrusion dies and die-casting, Extrusion dies and die-casting

Alloy Or Not Is Alloy

Special Use Mold Steel

Type Alloy Steel Bar

Specifications

Good Tensile Yield Ratio Spring Steel 1.0961
Various Type
On Time Delivery,large stock
Melting process
Sample free

Product Description

What are details of 1.0961 Steel ?
Name	Good Tensile Yield Ratio Spring Steel 1.0961 Steel Roll Bar
Features	1, Chromium vanadium type spring steel;
	2, Good wear and abrasion resistance;
	3, Excellent toughness and shock resistance.
Applications	1, Widely used in the motor vehicle industry;
	2, Suitable for many general engineering applications;
	3, Crankshafts, steering knuckles, spindles, pumps and gears.
Sizes	Round bar	Diameter(mm)	Length(mm)
		Max 800	Max 9000
	Plate	Thickness(mm)	Width(mm)	Length(mm)
		Max 800	Max 2200	Max 9000
	The above is our regular size, We also can provide customized sizes!
Packing	20ft: GW 27T; (5.80mX2.13mX2.18m) 40ft: GW 27T; (11.8mX2.13mX2.18m)
Price	The price will change according to the weight of the steel you need.

What is the similar steel grades?
AISI/SAE	DIN	JIS			SIAU		GB
9254	1.0961	SUP12			----		60Si2CrA
What are the chemical compositions?
C	Si	Mn	P	S	Cr	Ni	Cu
0.56-0.64	1.60-2.00	0.70-1.00	≤0.025	≤0.025	≤0.35	≤0.35	≤0.35

How about the surface treatment?
