Filter Cloth,non Woven Felt Fabric Rolls
US$ 1 - 15
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
Whitewing Headlining Cotton
Model Number:
DEF5
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Air Intake Filter RollUS$ 2 - 5MOQ: 100 Square Meters -
600g Filter Ceiling for Paint StopUS$ 2 - 5MOQ: 100 Square Meters
-
Spray Booth Roof Filter, 550g Filter MaterialUS$ 2 - 5MOQ: 100 Square Meters
-
Electrostatic Filter MaterialUS$ 2 - 5MOQ: 100 Square Meters
-
Roll Filter MaterialUS$ 2 - 5MOQ: 100 Square Meters
Place of Origin
Liaoning, China
Brand Name
Whitewing Headlining Cotton
Model Number
DEF5
Type
Non-woven Filter
Usage
Air Filter
Material
Other, Filter Cotton
Specifications
Filter cloth,non woven felt fabric rolls1.20mm
2.clear dust of 5um above
3.made in shutter style/platform
Filter cloth,non woven felt fabric rolls
| Filter media: 100% synthetic fiber |
| Primary filter grade: G2 G3 G4 |
| Fine filter grade: F5 F6 F7 |
| Thickness: 8mm 10mm 15mm 20mm 25mm |
| Width: up to 220mm |
| Testing standard: EN799 ANSI/ASHRAE 52.1-1992 |
| Working temperature: up to 120°C |
| Advantage: |
| 1.Solid penetrated glue |
| 2. Precuts for finished dimension |
| 3. Customer logo stamp avaiable |
| 4. Fire prevention |
| 5 Surface with netting or bonded fabric avaiable |
| Application: |
| 1. For pre filtration use |
| 2.Chemical plants |
| 3.Pharmaceutical and food industry |
| 4.Gas trubo and Co-generation utility plants |
| 5.Paint spray plants |
| 6.Pre-filtration and recycling or exhaust air |
| TYPE | Thickness | Wind Speed |
Initial Resistance |
Final Resistance |
Efficiency | Dust Capacity |
Thermal Resistance |
Humidity |
| mm | m/s | Pa | Pa | % | g/sqm | °C | % | |
| G2 | 10 | 2 | 20 | 120 | 73% | 320 | 120°C | 100 |
| G3 | 20 | 1.5 | 20 | 200 | 85% | 500 | 120°C | 100 |
| G4 | 20 | 1 | 25 | 200 | 92% | 470 | 120°C | 100 |
| F5 | 20 | 0.3-0.6 | 35 | 250 | 98 | 438 | 120°C | 100 |
| F6 | 20 | 0.3-0.6 | 55 | 300 | 99 | 425 | 120°C | 100 |
| F7 | 20 | 0.3-0.6 | 80 | 400 | 99.9 | 400 | 120°C | 100 |
