Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture)

Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) thumbnail-1
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) thumbnail-2
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) thumbnail-3
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) thumbnail-4
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) thumbnail-5
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) photo-1
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) photo-2
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) photo-3
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) photo-4
Cardboard Frame Panel Air Filter ,pleat Primary Filter ,G4 Air Filter (manufacture) photo-5
US$ 6 - 9.9 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Condition:
New
Efficiency:
93%-99%
Construction:
Panel Filter
Contact Supplier Request Quote Chat Now
Dandong Shifa Industry Filter Cloth Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Liaoning
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Efficiency 93%-99%
Construction Panel Filter
Filtration Grade Medium Filter
Medium Material Synthetic Fiber
Place of Origin Liaoning, China
Brand Name Whitewing
Model Number DDSF
Dimension(L*W*H) customize
Weight customize
Certification ISO9001
Warranty 45days
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Cardboard Frame Panel Air Filter
1.auto filter
2.long operations life
3.low price
4.high quality

Cardboard Frame Panel Air Filter

























cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)



Filter media: Synthetic fiber

Frame material: Cardboard,

liner: Galvanized mesh

Grade:G3 G4 F5 F6 F7

Temperature: up to 80°C

Testing standard: EN799 (dust-spot version)



Advantage

1. Disposable cardboard frame

2. Eco friendly

3. Enlarge the filter area by Pleated media

4. Fire prevention

5. Customer logo on the frame available



Application

1. Engineering and devices plants

2. Air condition,ventilation system

3. Paint stop

4. Pre filtration for HEPA filter





American& Euro

 Standard

 Inch size MM size Rated air flow
                    W×H×W(mm)        1.5m/s     2.5m/s    3.0m/s

G3=MERV5/MERV6

G4=Merv7/Merv8

F5=Merv9/Merv10

F6=Merv11/Merv12

F7=Merv13

       24×24×1       595×595×22 2040 3400 -
      20×24×1       495×595×22 1785 2975 -
      20×20×1       495×495×22 1445 2380 -
      12×24×1       287×595×22 1020 1700 -
      24×24×2       595×595×45 2040 3400 4250
      20×24×2       495×595×45 1700 2805 3570
      20×20×2       495×495×45 1445 2380 2975
      16×24×2       390×595×45 1445 2380 2675
      16×20×2       390×495×45 1105  1870 2380
      12×24×2       287×595×45 1020  1700 2125
      24×24×4       595×595×90 2040  3400 4250
      20×20×4       495×495×90 1455  2380 2975
      12×24×4       287×595×90 1020 1700 2125







 cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)

cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)



cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)



cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)





cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)

cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)

cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)cardboard frame panel air filter ,pleat primary filter ,G4 air filter (manufacture)
