Home > Packaging & Printing > Printing Machinery > Screen Printer > Water Labeling,ceramic Decals,printing Machine LTA-350

Water Labeling,ceramic Decals,printing Machine LTA-350

Name: Water Labeling,ceramic Decals,printing Machine LTA-350
Brand: Lingtie
SKU: 103316627
Availability: InStock

Water Labeling,ceramic Decals,printing Machine LTA-350 thumbnail-1

Water Labeling,ceramic Decals,printing Machine LTA-350 photo-1

US$ 20,000 - 40,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Fujian, China

Brand Name:

Lingtie

Contact Supplier Request Quote Chat Now

Lingtie (Xiamen) Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Fujian, China

Brand Name Lingtie

Model Number LTA-350

Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer

Automatic Grade Automatic

Voltage 220V

Gross Power 3KW

Dimensions(L*W*H) L2350 x W890 x H1580 mm

Weight 900kg

Certification ISO9001

Warranty One year warranty and life time maintenance

After-sales Service Provided Engineers available to service machinery overseas

Label,color labels for cars,printing machine

Main Features

Model No.	LTA-350	Printing material thickness	0.02-0.5 mm
Screen Frame Area	670x600mm	Squeegee angle	0-30°
Max. Print Area	350x350mm	Frame regulating variable	60 mm
Max. Paper Width	360mm	Bench height	930 mm
Printing Speed	20-70 t/min	Height of screen frame
Power	Main Drive Motor	0.37kw
	Pulling Drive Motor	1.5 kw
	Air Suction Motor	0.7kw
UV Drier UV	3.6x1kw (optional)
Machine Weight	Net Weight	900kg
	Gross Weight	1050kg
Power	220V 3KW (single-phase power)
	Remark: can be designed against your need
Machine Size	L2350 x W890 x H1580 mm
Packing size	L2450x W990 x H1600 mm

Main Features

1. Adopt Japan servo motor and CNC control system.running stability, high precision,high torque,fast speed and wear resistance.

2.Adopt Mitsubishi (Japan) frequency converter and adjusting device,easy to regulate speed, 20-70 prints/minute

3.Import Germany magic eye,good for color match and accurate.

4.Pre-set the quantity of sheets by electronic counter.QC lamp for chromatism.

5.Photo sensor auto-detection system for no films.

6.Double-sided scraper,extend service life.

7.Electrostatic painting,stoving varnish and solvent-resistance on the surface of machine.

8.Connecte to corona/die-cutting/slittingQC/ UV dryer and rewinder machine accroding to actual situation.

9.Only one person to operate,replace traditional and semi-automatic method.Improve six times of production efficiency, which reduce cost effectively.

Automatic feeding machine(double-side dedusting,removing film,electrostatic eliminating→)automatic pringing(punching,printing,QC)oven→automaticdeviation-correcting,rewinding and coronaing machine→automatic punching/cut machine→the end.

FAQ

Q: What is your MOQ of this machine.

A: 1set/set.

Q: What is your delivery time?

A: 25 days.

Q: Can you make particular design according to our requirements?

A: Yes,we can make a special change according to your requirement.

Q: Where is your Loading Port?

A: Xiamen.

Q: What are your payment terms?

A : 30% deposit and balance T/T against copy of Bill of Landing or L/C at sight.

Q; Where certificate can you pass?
