Help CenterMultilayer PCB for Led
US$ 0.1 - 10
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Base Material:
FR4
Copper Thickness:
1oz
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Base Material
FR4
Copper Thickness
1oz
Board Thickness
1.6mm
Min. Hole Size
0.1mm
Min. Line Width
0.1mm
Min. Line Spacing
0.1mm
Surface Finishing
Immersion Gold
Specifications
Over 12 years experience in Multilayer Printed Circuit BoardPCB+Components+Assembly
Approval: UL,ISO9001,ROHS
We have 12 years experience in PCB filed to service you need. We can offer 1 to 20 Layers Printed Circuit Board fabrication, especially Multilayer pcb,HF PCB,flexible PCB and rigid flex PCB are what we mainly deal with.
Our PCB production capacity
| PCB Item | Manufacture Capacity |
| Layer Counts | 1--20L |
| Base Material | FR4,High-TG FR4,CEM3,aluminum,High Frequency(Rogers,Taconic,Aron,PTFE,F4B) |
| Material Thickness(mm) | 0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2 |
| Max board size(mm) | 1200x400mm |
| Board Outline Tolerance | ±0.15mm |
| Board Thickness | 0.4mm--3.2mm |
| Thickness Tolerance | ±8% |
| Minimum line/space | 0.1mm |
| Min Annular Ring | 0.1mm |
| SMD Pitch | 0.3mm |
| Holes | |
| Min Hole Size(mechanical) | 0.2mm |
| Min Hole Size(laser hole) | 0.1mm |
| Hole Size Tol (+/-) | PTH:±0.075mm;NPTH: ±0.05mm |
| Hole Position Tol | ±0.075mm |
| Plating | |
| HASL/LF HAL | 2.5um |
| Immersion Gold | Nickel 3-7um Au:1-5u'' |
| Surface Finish | HAL,lead-free HAL,ENIG,Plated Gold,Immersion Gold,OSP |
| Copper | |
| Copper Weight | 0.5--6oz |
| Color | |
| Soldermask | Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue |
| Silkscreen | White, Black, Blue,Yellow |
| Acceptable File Format | Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000 |
| Certificate | ROSH,ISO9001,UL |
Our PCBA Competence:
| Stencil size/range: | 736x736mm |
| Minimum IC pitch: | 0.30mm |
| Maximum PCB size: | 1200x 500mm |
| Minimum PCB thickness: | 0.35mm |
| Minimum chip size: | 0201 (0.2x0.1)/0603 (0.6 x 0.3mm) |
| Maximum BGA size: | 74x74mm |
| BGA ball pitch: | 1.00mm (minimum), 3.00mm (maximum) |
| BGA ball diameter: | 0.40mm (minimum), 1.00mm (maximum) |
| QFP lead pitch: | 0.38mm (minimum), 2.54mm (maximum) |
| Frequency of stencil cleaning: | 1 time/5 to 10 pieces |
If you need to get a formal quoation,please provide the spec as below:
1. PCB files in gerber file, .pcb or .pcbdoc formart
Welcome to contact Fulltronics team. We are here ready to assist you with our professional skills and cheerful services.
