high voltage electrical insulation rings
- 100000 Piece / Pieces per Month
- Ningbo Shanghai
- T/T Credit Card
- Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
- High Viscosity 3W/MK Thermally Conductive Putty For BGA Package
- 3240 Epoxy Board, High-quality Insulation Material, Flexible Customization, Widely Applicable 3240 Epoxy Sheet
- Chinese Factory Electrical Insulation Brown 3025 Phenolic Bakelite Resin Cotton Cloth Fabric Laminate Board Sheet Phenolic Board
- 4x8 fiberglass sheets g10 epoxy glass fiber board g10 material
- Factory Price Bakelite Decorative HPL Press plates bakelite sheet
Product Details
Brand Name: | OURSOLID | Type: | Insulation Sleeving | Material: | Fiberglass |
Application: | High Temperature | Rated Voltage: | 40KV | Tensile Strength: | 600MPA |
Product Description
Diameter range: from 8mm to 800mm
Max length:12m
Thickness :0.5mm-more
We can design and make it by your drawing.
OURSOLID major products: high-load self-lubricating bearing,special composite tubes, etc., and main bearing widely used for Engineering machinery, construction machinery, medical machinery, packaging machinery, food machinery, ship machinery, aerospace fields, electrician and electrical field.
OURSOLID major customers: Institute of Plasma Physics, Chinese Academy of Sciences, Huazhong university of science and technology, Liugong machinery, saint-gobain, Morgan, GE, Japan's Mitsubishi, Japan high voltage electric, Siemens and other international well-known companies.We have provided services for over 100 enterprises in China, America, Europe, Japan, South Korea, Argentina, India, Taiwan, and other countries and regions.
High Load Self-lubricating Bearing
1) Used dry
2) High Load
3) Light weight
4) Corrosion resistance
5) High temperatureresistance
Basic type | Unit | B-21 High Load | B-06 Standard | B-03 General | B-01 Economic |
Static load | Mpa | 240 | 240 | 240 | 150 |
Dynamic load | Mpa | 160 | 150 | 100 | 30 |
Density | g/cm3 | 2.0 | 2.0 | 2.0 | 2.0 |
Max.speed | m/s | 0.20 | 0.20 | 0.20 | 0.10 |
Max.PV | MPa*m/s | 2.0 | 2.0 | 1.8 | 1.6 |
Coefficient of friction | - | 0.03~0.12 | 0.03~0.12 | 0.03~0.12 | 0.15~0.25 |
Working Temp. | ℃ | ±180 | ±180 | ±180 | ±120 |
SHORT-TIME WORK TEMPERATURE | ℃ | -180~+230 | -180~+230 | -180~+230 | -120~+140 |
Radial compressive strength | Mpa | 550 | 550 | 550 | 200 |
Hardness | HRM | 95 | 95 | 95 | 85 |
Linear thermal expansion factor | Um/m℃ | 13×10-6 | 13×10-6 | 13×10-6 | 30×10-6 |
Color | - | Black
| Black
| Black
| Black
|
Note : Instead of GGB High Strength GAR-MAX style
FRP pipe is Epoxy glass fiber reinforced entwined tube
1) Excellent mechanical strength,
2) High mechanical load
3) Endure high Voltage ,10-1000KV
4) Light weight
5) Adjust the winding angle to satisfied with your any mechanical strength demand
6) Thickness is from 1mm to more 7) Work temperature:B (125C)/ F(155C)/ H(180C)/ 220-250 C
Item | Uint | Value | ||
Density | g/ cubic centimeters | more than 1.9 | ||
Compression Strength | Mpa | more than110 | ||
Shearing Strength | Mpa | more than 25 | ||
Bending Strength | Mpa | more than210 | ||
Bending Strength(Circumference) | Mpa | more than 400 | ||
Air tightness | Gas pipe | Mpa | 2.94 | No leak |
Oil pipe | 58.8 | |||
Surface breakdown voltage after wettingin normal air for 1 min with gap between electrodes of 30mm | KV | more than15 | ||
Parallel to laminate breakdown voltage ( in transformer oil of 90±2ºC) | KV | more than 25 | ||
Perpendicular to laminate breakdown voltage (in transformer oil of 90±2ºC,5min wallthickness 4mm ) | KV | more than 22 | ||
Dielectric loss factor 50 Hz | less than0.01 | |||
Leakage current (between gap of 500mm at 40 kv dc500mm40KV | MA | less than 1 | ||
Content of fiberglass | % | 70 | ||
Water absorbtion rate | % | less than 0.02 |
The above data is only for reference, our sleeve parameters are customized according to customer demands.
OURSOLID is one of the most professional manufacturers of composite material products. OURSOLID continuously introduces and absorbs international advanced production technology, continuously develops products with international competitiveness by market orientation, and serves global electricity, machinofacture and other industrial fields, by many years of experience in research of composite materials.
1.Packaging dimension&detail
Packing: Air bubble films and carton or as the customer’s requests
2.Shipping methods
Small order: By express,DHL,UPS,FEDEX,EMS
Large order: By sea or by air
Choose the best and convenient way for your demands
3.Payment & delivery time
Payment:
We accept T/T,L/C,D/A,D/P and Western Union
For small account,we suggest pay by Western Union
Delivery time:
10-30 days after payment in advance
Ordering is easy,we help you every step of the way...
Need a sample? We can offer you one!
If you want a product sample before placing the order, we will be glad to send you a good sample immedia tely so that you can check it out to make sure if it makes you satisfied.
FREE technical assistance available for you.
If you have problems in designing or others, we will offer you the best technical assistance. All you need to do is just to give us the image or words you require for the product and we will de sign and print them for you!
Careful, professional service for your order.
We have a professional team of customer service that offer you the best experience of dealing with Explor ecn. With professional customer service and art assistance staff working hard to make your order perfect, you will feel like they are members of your own company that can help you in every aspect.
Need sourcing in hurry ?
As you all know, we are a promotional manufacturers of composite material products in China ,so we are able to make your order into reality in the shortest time!
Immediate response to your request!
We know time is money, do not hesitate to contact us with phone, e-mail or live chat, we will make immediate response to your question in no time!
Give us an opportunity!
We will greatly appreciate that you come to us to purchase various kinds of?promotional products?custom products?and?advertising products. We can be sure that you will get the greatest price and service from us because we have advantages that other companies do not have which is one-stop service. Besides, as a customer of OURSOLUID, you will enjoy the best customer service, free art assistance, fast responding to yo ur inquiry, good product quality and ideal experience of shopping online!
1.One stop service ( no more difficulties orders from China directly)
2.Over 10 years experience, solving all problem advanced save time and cost
3.Best price based on our smart solution and supply chains management
4.Strict quality control through our QC team 5.Share with ideas for marketing products and consulting for production
5.Share with ideas for marketing products and consulting for production
6.Good work team to win the market in your country, can be good sourcing agent in China
7.Big discount for shipping based on our large export
Customer Service
We understand purchasing is the most complicated and cumbersome work. Various trade platform can not display all contents of purchasing. Only a responsible supplier who always standby can undertake this task. Large scale operation can maintain our cost advantage and maintain quality. Low labor cost and large nu mber of factories in China provide rich resources for us. We are responsible for purchasing and production, so that our customers can put together advantages to develop market. We look forwarder to establish lon g term cooperation with our client, and we provide more services to make it eaiser.
- Free technical assistant
- Quality control on every single order based on SGS AQL 2.5-4.0
- Online order tracking
- Member pricing online checking
- Ideas share
- New products alerts
Contact Us
- Ningbo Oursolid Composite Material Co., Ltd.
- Contact nameSteve Liu
- Phone86-0574-88394393
- AddressPingtang Industry Zone 88# , Dongwu Town of Yinzhou Area Ningbo,Zhejiang
