SINOSUN MBM25 mobile concrete mixing plant
MBM25 Mobile Concrete Mixing Plant is a new type of mobile concrete mixing station, which adopts advanced technology and scientific research results from home and abroad.Electronic control system components are imported. The overall performance is stable and powerful.
The specialty of MBM25 Mobile Concrete Mixing Plant is that it is mobile with pneumatic braking or towing attachment by a tractor.
Features of mobile concrete mixing plant:
1. These concrete mixing plants are truly portable type plant with king pin attachment and pneumatic braking system.
2. These mobile concrete plants are built on a single sturdy chassis.
3. Other features such as accurate weighing, homogeneous and efficient mixing, fast and clean delivery, convenient to move and operate, safe trailing, etc.
Advantages of mobile concrete mixing plant:
1. Our mobile concrete mixing plants require less installation area required due to its compact design. Our mobile batching plant is popular for its quick and easy installation and operation in 2-3 days to start concrete production and one day for disassembling.
2. Our mobile concrete mixing plant gives you the advantage of direct feeding of mixed material into transit mixer or concrete pump. With our mobile concrete mixing plant, the concrete transportation cost can be minimized.
This series of mobile mixing plant is the ideal choice for projects that require frequent movement from one construction site to another.
Primary Competitive Advantages of SINOSUN concrete mixing plant :
- Brand-name Parts
- Country of Origin
- Experienced Staff
- Green Product
- Guarantee/Warranty
- International Approvals
- Price
- Product Features
- Product Performance
- Prompt Delivery
- Quality Approvals
- Reputation
- Service
- Small Orders Accepted
MBM25 mobile concrete mixing plant | ||
Capacity (m³/h) |
25 |
|
Mixing Time (s) |
60 |
|
Discharging Height (m) |
3.8 |
|
Total Power (kw) |
35 |
|
Max Aggregate Size (mm) |
Gravel |
60 |
Pebble |
80 |
|
Dimension (mm) |
L |
14500 |
W |
4050 |
|
H |
7600 |
|
Total Weight (t) |
20 |
|
Main components of MBM25 mobile concrete mixing plant
No. |
Components |
Main Equipments |
1 |
Mixing System |
JS500 Twin-shaft Concrete Mixer(0.5L) |
2 |
Aggregate Batching System |
PLD800 Aggregate Batcher(4x4m3) |
3 |
Cement System |
20T Cement Silo |
4 |
Additive System |
1m3 Additive silo |
5 |
Water System |
Water Pump |
6 |
Air System |
Air Compressor |
7 |
Weighing System |
Cement, Water, Additive Weighing Equipments |
8 |
Control System |
Fully-automatic Control Equipments |
