Hyva flash hoist-FC series telescopic hydraulic cylinders

Name: Hyva flash hoist-FC series telescopic hydraulic cylinders
Brand: Salid
Availability: InStock

FOB Price

USD $39 - $80 / Piece

1 Piece(Min.Order)

Supply Ability 5000 Case / Cases per Month
Port qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Standard or Nonstandard	Nonstandard	Structure	General Cylinder
Power	Hydraulic	Body Material	Steel
Maximum Stroke	50"	Shaft Diameter	2"
Place of Origin	Shandong, China	Model Number	HT
Brand Name	Salid

Product Description

Hyva flash hoist-FC series telescopic hydraulic cylinders

Product Description

1.Rod End Cross Tube		High tensile steel
2.Gland		Ductile iron ASTM A536 65-45-12
3.Rod		High tensile SAE C1045, ground & polished hard chrome plated rod
4.Tube Weldment		High tensile cold drawn tube, precision honed for extended seal life
5.Port Plug		Plastic
6.Grease Fitting		M6 (standard included)
7.Base End		High tensile cast steel
8.Piston nut		Jam nut, grade 8, high tensile zinc-plated
9.Piston		Ductile iron ASTM A536 65-45-12, type A & type B piston available
A. Piston ID seal(B type piston)		O-ring(1)+back up ring(2)
A. Piston ID seal(A type piston)		O-ring(1)+back up ring(2)
B. Piston OD seal(B type piston)		Bronze impregnated PTFE piston ring w/rectangular CS nitrile expander
B. Piston OD seal(A type piston)		Polyurethane U-cap
C. Tube seal		O-ring(1)+back up ring(1)
D. Rod seal		Polyurethane U-cap
E. Wiper		Metal canned wiper

Custom Hydraulic Cylinder

We can supply customized hydraulic cylinders with drawings or samples, or if you could provide following specification:

•diameter of bore & rod
•stroke
•mounting style
•mounting distance
•working pressure
•ports
•seals
•special modifications.

Widespread Application

We specialize in design and manufacture hydraulic cylinders that are used in a variety of fields including:

•Construction Machinery cylinders for: loaders, excavator, forklift, bulldozer, dumper, roller, crane etc.
•Metallurgical Machinery cylinders for: decelerator, tile press etc.
•Mining Machinery cylinders for: crasher, coal cutter etc.
•Agricultural & forestry machinery cylinders for: soil preparation machine, harvester, weeder etc.

Qingdao Salid Machinery CO.,LTD.
Product
tie rod hydraulic cylinder, welded hydraulic cylinder, telescopic cylinders cylinder, flange type hydraulic cylinder, hydraulic cylinder with valve function, hydraulic power unit, Hydraulic manifold block, pneumatic fitting,
Material	Tube — Cold Drawn Precision seamless Tubing End Caps — Steel, threaded fixed; Wear Ring — Nylon Backup Washer Rod Seals — Polyurethane U-Cap Rod — Chromed, ground & polished piston rod Mounts — Trunnion with angular Swivels Rod Wiper — Polyurethane
Application	Agriculture, Concrete & Asphalt, Cranes, Fire & Rescue, Forestry & Logging,Mining & Rock Crushing,Oil & Gas, Snow & Ice Control,Waste Management and Material Recycling Industry , Engineering Equipment, Special Vehicle
Feature	1.High quality with a reasonable price 2.ISO9001-2008 3.Customized specification are accepted
Payment	T/T;L/C,WESTERN UNION.
Port	Qingdao ,China
Quotation	According to the specific request
MOQ	According to the product
Packaging	metal case;plywood case;carton or as requirement
Delivery time	30days upon receipt of 30% deposit; or upon receipt of relevant L/C;
