pulp and paper refiner

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port Qingdao/ Tianjin
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Pulping Equipment
Computerized	No	Place of Origin	Henan, China
Brand Name	Dingchen	Certification	ISO9001:2000
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

Standard export Wooden case ,also can be packed as customers' request

Product Description

Uses and Features:

ZDP Series double- disc refiner adopts mechanical seal, It is a ideal continuous beating equipment ,

has a compact construct, small footprint, high efficiency, low power consumption, adaptability,

simple operation, flexible adjustment and easy maintenance , a reliable seal to prevent leakage.

Technical parameters:

Model	ZDP380	ZDP450	ZDP550	ZDP600
The diameterofthegrinding piece(mm)	380	450	550	600
Production capacity (t/d)	6-20	8-40	25-80	40-120
Into the pulpconcentration (%)	2-5	2-5	2-5	2-5
Into the pulppressure (Mpa)	0.1-0.3	0.1-0.3	0.1-0.3	0.1-0.3
With motor(kw)	37-55	75-110	132-160	160-250
Weight(kg)	1250	2000
Dimensions(mm)LWH	2150×700×750	2855×1360×830

Item	Type
Item	ZYPM-380	ZYPM-450
Disc Diameter mm	380	450
Production capacity t/d	6~20	8~40
Into the pulp concentration %	2~5	2~5
Into the pulp pressure MPa	0.1~0.3	0.1~0.3
A pulppipediameter mm	80	100
With motor KW	Y250M-6/37-55	Y315M-6/90
Equipment weight kg	1250	2000
dimensions (L × W × H mm	2050×615×650	2855×1360×830

Company Profile

Zhengzhou Dingchen Machinery Co., Ltd.

Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines. Our company has over 420 employees. We have passed ISO14001 International Authentication. Our products include paper making machines, parts and paper processing machines such as kraft paper machines, tissue paper machines, cultural paper machines, fiber separators, hydrapulpers, rewinders, napkin folders, tissue slitters and so on. They have been exported to more than 8 countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying on advanced technologies, sincere services and inexpensive products of high quality, we have won the recognition of international markets and clients.
