2400mm newsprint paper making machine
Main technical parameters:
1, papermaking variety | cultural paper |
2, papermaking quantitative | 50-90g / m2 |
3, net paper width | 2400mm |
4, net width | 2800mm |
5, working speed | 150m/min |
6, the design speed | 180m/min |
7, capacity | 30T / D |
8, rail distance | 3200mm |
9, transmission | Frequency Control, Division Transmission |
Structure of main part:
1.Cylinder section: Φ1500mm×1950mm cylinder mould 2 sets, Φ450mm×1950mm couch roll 2 set, φ400×1950mm reverse roll 1set,
rubber shore hardness 38±2.
2.Press section: Φ500mm×1950mm marble roll 1 set, Φ450mm×1950mm rubber roll 1 set, rubber shore hardness 90±2.
3.Dryer section:Φ2500mm×1950mm dryer can 2 set,Φ500mm×1950mm touch roll 1 set,rubber shore hardness 90±2.
4.Drive way AC inverter speed, section drive.
5. Pneumatic compression device.
NO. | name | quantity(set) |
1 | 2400mm paper making machine | 1 |
2 | dryer can exhaust hood | 1 |
3 | 850axial-flow ventilator 850 | 1 |
4 | 15type roots vacuum pulp | 1 |
5 | suction box | 6 |
6 | 2400mm winding machine | 1 |
7 | three roll calendar | 1 |
8 | 2400mm rewinding machine | 1 |
9 | pulp spray vat former | 2 |
10 | 10m3high consistency hydrapulper | 1 |
11 | up-flow pressure screen | 1 |
12 | high frequency vibration screen | 2 |
13 | 606type desander(10pcs) | 1 |
14 | IS250-200A desander pulp | 2 |
15 | ZSL1.2m2centrifugal screen | 1 |
16 | Φ380mm double disc refiner | 3 |
17 | 14m3vat thicker | 1 |
18 | Φ700mm thruster | 6 |
19 | 4 inch pulp pump | 10 |
20 | 6 inch pulp pump | 8 |
21 | frequency conversion controlling cabinet | 1 |
22 | air pump cabinet | 1 |
23 | work table | 1 |
Deliverying
Perfect service:
nical consultation
2.detailed design of factory or workshop
3.training engineers and workers
4.supplying spare part for long time
5.installing and testing the whole production line
6.good after-sale and in-sale servcie
