Ring-tread Curing Press HYLT-series

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Sichuan, China
Brand Name	YALUN	Model Number	HYTL
Voltage	can be customized	Power(W)	7kw
Dimension(LWH)	203023802600	Weight	about 6 ton
Certification	ISO9001	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

1.higher pressure,more strength.
2.easily handled.
3.lower investment,higher precured tread

Function:

Ring-tread curing press HYLT series are used to manufacture ring tread in preparation for the casing in cold retreading.

back view of the HYLT Ring Press

Features:

Yalun patented product, patent No. 200820141465.9 200820141466.3
Inner and outer chambers make sure steam or oil heating equally on tread rubber to shorten then curing time, approximately 25 minutes per cycle.
Eight cylinders around tread rubber. Pressure is as high as 50kg/cm2 to have a much more better wear and puncture characteristic than usual tread rubber.
Inner chamber is movable on diameter and has a mechanical locking unit to not only easy put in/out tread rubber but also make sure the safety when curing.
Vertical model with a movable core mold is not only easy to put in/out tread rubber but also keeps steel wires from distortion.
Tread rubber is with steel wires insides so as to be suitable to move kinds of tyre casing which need not to be strictly selected as usual.

Ring Tread Manufactured by our HYLT Ring Press

ring tread mold

Specifications:

Model	HYLT-12.00/11.00	HYTL-10.00/9.00	HYTL-8.25/7.50
Tyre size range	11.00-12.00R20	9.00-10.00R20	7.50-8.25R20
Dimension (mm)	2100×2450×2650	2030×2380×2600
Rated curing pressure (MPa)	6
Steam pressure (MPa)	<0.7
Power supply	AC380V,AC220V,50HZ
High pressure Pump ( Mpa)	17	13	16
Station pressure Low pressure Pump ( Mpa)	2.5
Electric machine power (KW)	7
Weight (t)	About 7	About 6
