Home > Products > A2 For Cold Retreading > Electric Tire Curing Chamber
Electric Tire Curing Chamber
US$ 26,870 - 44,780
/ Unit
1 Unit(Min. Order)
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Sichuan, China | |
| Brand Name | YALUN | Voltage | can be customized | |
| Certification | ISO9001 | Warranty | 1 year |
Product Description
Specifications
Vulcanizing Tank is curing chamber1.safety and low failure rate.
2.high quality,competitve price.
3.export to South Africa.
Vulcanizing Tank is used for the second curing of the retreading tyre,and it can be heated by means of electricity, steam or diathermic oil.curing tank.
Tyre number12.00R20 | 12 | 14 | 16 | 18 | 22 | 25 |
Theoretical steam consumptionkcal/h | 43000 | 52000 | 60000 | 65000 | 70000 | 90000 |
Electric hot-tube power--electrickw | 50 | 60 | 70 | 75 | 80 | 100 |
Electric hot-tube power--steamkw | 8 | 8 | 9 | 9 | 12.5 | 12.5 |
Fan motor powerkw | 4 | 4 | 5 | 5 | 11 | 11 |
Width--uncovered mm | 5900 | 6600 | 7400 | 7800 | 8900 | 9900 |
Width--covered mm | 5100 | 5800 | 6600 | 7100 | 8100 | 9100 |
Practicable work widthmm | 3600 | 4200 | 5000 | 5500 | 6800 | 7500 |
heightmm | 2200 | |||||
depthmm | 2900 | |||||
weightt | 4.6 | 4.9 | 5.3 | 5.52 | 5.9 | 6.4 |
Designed pressureMPa | 0.9 | |||||
Maximum work pressureMPa | 0.8 | |||||
Experimental pressureMPa | 1.1 | |||||
Designed temperature(c) | 180 | |||||
Power supply | AC380V,AC220V,50HZ | |||||
Compressed air sourceMPa | 0.8 | |||||
retread tires
