Specifications
High Quality Wind Power System1.CE approved
2.Good price high efficiency
3.On time delivery.
3KW Low Speed Wind Power Generator for sale
1.Product Parameters and Features
| 3kw Vertical Axis Wind Turbine Generator ON-GRID | |
| Power | 3000W |
| Type of generator | Permanent-magnet 240v A.C. |
| Rotor diameter: | 3m |
| Blade Material: | FRP (Fiber glass reinforced*5) |
| Rated rotor speed | 120r/min |
| Rated speed | 11m/s |
| Rated Power | 3000W |
| Max Power | 3500w |
| Start up wind speed | 3(m/s) |
| Work speed | 3-25(m/s) |
| Security wind speed | 40(m/s) |
| Height of guy cable tower | 8m |
| Top quality except tower | 420kg |
| Output controller system | Controller , Inverter |
| 3kw Vertical Axis Wind Turbine Generator OFF-GRID | |
| Power | 3000W |
| Type of generator | Permanent-magnet 120v A.C. |
| Rotor diameter: | 3m |
| Blade Material: | FRP (Fiber glass reinforced*5pcs) |
| Rated rotor speed | 120r/min |
| Rated speed | 11m/s |
| Rated Power | 3000W |
| Max Power | 3500w |
| Start up wind speed | 3(m/s) |
| Work speed | 3-25(m/s) |
| Security wind speed | 40(m/s) |
| Height of guy cable tower | 8m |
| Top quality except tower | 380kg |
| Output controller system | Controller , Inverter |
1.Low starting torque
2.Low start wind speed
3.Low speed permanent magnet generator
4.No vibration & low noise
5.All of our products confirm to CE
6.PWM constant voltage recharge function provides stable output
7.Reliable wind power system by multifunction controller
8.On-grid or Off-grid wind power system optional
9.2-year warranty for generator and 18-20 years service life.
10.Electronic brake and manual brake, optional.
11.High efficiency and Low mechanical resistance energy loss.
2. Controll System (On-Grid)
Pure sine wave inverter
Rated Battery Voltage: 120V
Rated Output: 3KW
Over Voltage Shutoff: 170 VDC
Over Voltage Recovery: 165 VDC
Under Voltage Shutoff: 105 VDC
Under Voltage Recovery: 120 VDC
Output Wave Form: Pure Sine Wave
Display Mode: LCD
Rated Output Voltage: 220 VAC
Output Frequency: 50 Hz±0.05Hz
Inverter Efficiency: More than 90%
Protection Function: Battery over voltage protection, Battery under voltage protection, Battery reverse-connection protection, Output over load protection, Output short circuit protection, Over temperature protection.
Micro-computer intelligence controller
Rated Battery Voltage:120V
Rated Wind Turbine Maximum Power: 3KW
Rated Wind Turbine Maximum Input current:50A
Rated Wind Turbine Maximum instantaneous Input power:6KW
Unload Voltage (factory default):140V
Unload Current (factory default):30A
Rated PV Power: 900W
Control Mode:PWM
Display Mode:LCD
Range of working Temperature &Humidity: -20~+55°C/35~85%RH(Without Condensation)
Protection Type: Solar cells reverse charging, solar cells anti-reverse, battery over charge, battery over-discharge, battery anti-reverse, lightning protecting, wind turbine current limitting, wind turbine automatic brake and manual brake.
3. Notes
a. Tower type and tower height can be changed as per your request.
b. Working voltage can be special requested.
c. For the details, please feel free to contact us.
4. Company Profile
Qingdao Richuan Precision Machinery Co., Ltd., located in a nice coastal city called Jiaonan is a hi-tech company specialized in research & development, production, sales and service of medium and small wind turbines and devoted to the development and utilization of natural environmental protection energy such as wind energy, solar energy, etc.
The main products of our company include off-grid and grid-connected wind turbines, wind turbine blades and wind solar lighting system. They are widely used in agricultural and pastoral areas, mountainous areas, islands, frontier defence sentries and observatories with no electricity or insufficient electricity and rich wind resources.
Our company has advanced equipment and manufacture process, complete quality management system and excellent technical team to provide high quality and environment-friendly products and improved power supply solution and first-class after-sales service for customers.
High quality and competitive price guarantee us a huge market all over the world , such as in Eastern Asia , Europe , North America ,South America and Middle East .
5. Pictures for Your Reference
6.CE
